24V UNIVERSAL DIMMABLE LED DRIVER 24W (CLASS 2) - WHITE JUNCTION BOX

Name: 24V UNIVERSAL DIMMABLE LED DRIVER 24W (CLASS 2) - WHITE JUNCTION BOX
Brand: LED MONTREAL
SKU: 24DIMP24-W
Price: 64.97 CAD
Availability: InStock

SKU: 24DIMP24-W

Brand: LED MONTREAL

Finally, a way to dim your LED strips with the wall dimmer you already have. The 24V Universal Dimmable LED Driver 24W (Class 2) from LED MONTREAL, SKU 24DIMP24-W, is a constant voltage LED power supply — what people also call an LED transformer, LED driver, or strip light power supply — built into a clean white junction box. It takes your standard household power and turns it into smooth, stable 24V DC for your single-colour LED strip lights, and it lets a regular 110V wall dimmer control the brightness directly. No app, no remote, no separate dimming module: just the switch on the wall, exactly the way homeowners and contractors expect a light to behave.

Under the hood, this is a Class 2 driver with an input of 100 - 120V AC and an output of 24V 1A 24W, so it powers any 24V single-colour tape that stays within 24 watts total. It dims with a 120V AC dimmer and takes your strips smoothly from 100% down to 20% without noise or flickering, and it does not require a minimum load to perform — a real advantage on short runs of tape. The power supply itself measures 15.3 cm x 5.2 cm x 2 cm and sits inside a white junction box measuring 35 cm x 7.5 cm x 3.6 cm, keeping the wiring tidy and finished. It is cETLus certified for Canada and the USA, so it passes inspection on residential and commercial jobs alike.

Use it under kitchen cabinets, in a bathroom vanity cove, along a staircase, in a basement ceiling detail, behind a headboard, or in retail display cases and reception desks where a simple dimmable LED strip does all the work. One important note before you order: this driver is strictly for single-colour LEDs. If your project uses RGB, RGBW or CCT-adjustable tape, dimming has to run through an LED controller with a non-dimmable driver instead — and the same applies if you want to control single-colour strips from a controller. Pair this 24V LED driver with the white junction box already installed and your dimmable strip lighting project is one wire pull away from done.

Compatible with
Works with:
LED strip: 2216A-3000, 24BND2835SO-3000, 24RGB150, 24RGB15067, 24RGB150IP20, 24RGB300, 24RGB30067, 24RGB300IP20

Built for real wall dimmers
Most LED strip installations fall apart at the dimming stage: the driver buzzes, the tape flickers at low output, or the dimmer needs a minimum load it never sees. The 24V Universal Dimmable LED Driver from LED MONTREAL was designed around that exact problem. It works with any recent standard wall dimmer, dims from 100% to 20% without noise or flickering, and needs no minimum load, which is what makes it comfortable on small accent runs as well as longer cabinet installs. Because the dimming happens on the line side with a familiar 120V AC dimmer, there is nothing new for the client to learn — they walk in, slide the switch, and the light responds.

Constant voltage output and the junction box
This is a constant voltage LED driver: it holds a steady 24V DC while the LED tape draws what it needs, up to the rated 24W. The unit ships mounted in a white junction box, so the line-voltage connections are enclosed and finished rather than left loose above a ceiling or inside a cabinet gable. The white housing blends into painted drywall, closet interiors, vanity cabinets and utility spaces, and gives the installer a proper place to land the supply conductors and the low-voltage leads in one tidy spot.

Technical specifications
SKU: 24DIMP24-W
Brand: LED MONTREAL
Manufacturer marking: CDNLUX
Input: 100 - 120V AC
Output: 24V 1A 24W
Class: Class 2
Dimmable: Yes, with a 120V AC dimmer
Junction box colour: White
Power supply dimensions: 15.3cm x 5.2cm x 2cm
Junction box dimensions: 35cm x 7.5cm x 3.6cm
Certification: cETLus for Canada and USA

Compatibility and sizing
Match the driver to the load: add up the wattage of the 24V LED strip you plan to run and keep the total within the 24W output. Longer or higher-output runs are simply split across additional drivers or handled by a larger power supply. Compatibility is the part to read twice — this model is meant for single-colour LED tape only. RGB, RGBW and CCT-adjustable strips must be dimmed through their own LED controller fed by a non-dimmable driver; a single-colour strip driven by a controller also calls for a non-dimmable driver. Being Class 2, the output side stays in low-voltage territory, which keeps LED tape work straightforward for residential and light commercial installs.

Where it earns its keep, and documentation
Think under-cabinet kitchen lighting that dims down for evening coffee, a bathroom mirror cove on the same dimmer as the ceiling fixture, stair nosing lighting in a finished basement, cove lighting in a living room bulkhead, or warm display lighting in a boutique, café or clinic reception. In Canadian homes and businesses where a wall dimmer is already roughed in, this dimmable LED driver lets you add strip lighting without adding a control system. The technical PDF spec sheet for the 24V DC power supply 24W is available in the Documentation tab of this page, with the electrical values, dimensions and certification details to hand to your electrician or inspector.
