Built to take a little weather
The 24V 5M IP67 RGB 5050 weatherproof LED strip is wrapped in an iP67 coating that shields the chips and circuit from dust and temporary water exposure. That makes it a solid choice for humid rooms and protected outdoor spots, but it is not meant to be submerged or left permanently in standing water. The base is a flexible 12mm-wide board with a 2 Ounces copper layer — more copper means better current distribution and cooler operation across the full 5 meters. Strong 3M self-adhesive backing is factory-applied, so on clean, dry, degreased surfaces the run sticks the first time. On rough, textured or outdoor surfaces, aluminum channel or mounting clips remain the smart move.
Colour you actually control
Each Epistar 5050 RGB SMD chip carries red, green and blue emitters in one package. Mixing those three channels at different levels is what gives RGB strips their huge colour range, and the number of scenes, fades and transitions you get depends entirely on the RGB controller you pair with it. Keep in mind that an RGB chip does not produce a true white — if crisp task lighting or warm white ambience is the goal, a dedicated white or RGBW strip is the better tool, and many installers run both side by side. With a 120° lighting angle and 30 LEDs per meter, light spreads wide and blends quickly, which is exactly what you want inside a cove, a channel with a diffuser, or behind a panel.
Technical specifications
SKU: 24RGB15067
Model: MTL-FP10AGIWM-60ARGB
Certification: cULus for Canada and USA E498952
Chip: Epistar 5050 RGB SMD
Circuit board: 2 Ounces
Chip density: 30 LEDs per meter
Can be cut: All 6 LEDs (165.5mm)
Length: 5 meters
Width: 12mm
Height: 5mm
Voltage: 24V DC
Power consumption: 7.2W/m
Recommended power supply: 9W/m
Colour: RGB (Red, Green, Blue)
Lighting angle: 120°
Lifespan: 50 000+ Hours
iP rating: iP67
Operating temperature: 40C to -10C
Dimmable: Yes, with a low voltage controller/remote combo
Wiring and installation
This is a 24V DC low-voltage system, so it needs a dedicated power supply — never connect it straight to line voltage. Size the driver on the recommended 9W/m figure rather than the 7.2W/m draw, which keeps the supply from running at its limit. Connections are already made easy: a 4 pin male connector (17cm) sits on one end and a 4 pin female connector (17cm) on the other, matching standard RGB controllers and extensions. Cut only on the marked points, every 6 LEDs (165.5mm), and solder or use a 4-pin clamp connector to rejoin sections while respecting the polarity and the R, G, B channels. Heat dissipation is not necessary in most residential installs, though a commercial environment with long hours of operation benefits from aluminum channel to pull heat away. Dimming and colour changes are handled by a low voltage controller/remote combo, not by a standard wall dimmer.
Where it works and what is on the page
Picture it under a kitchen island for evening colour, along a basement bulkhead for movie nights, behind a floating vanity, inside display shelving in a boutique, around a restaurant bar, under a covered deck railing, or as accent lighting on signage and trade show booths. The 40C to -10C operating range and iP67 rating cover Canadian shoulder seasons on a sheltered porch or soffit, while the 50 000+ hour lifespan and cULus certification (E498952) reassure both homeowners and contractors specifying for a client. The full technical PDF for the 24V CUL SUPER BRIGHT IP67 WEATHERPROOF 150 LED RGB LED STRIP is available in the Documentation tab — download it before ordering your power supply and controller so every piece of the system lines up.
