LED ALUMINUM PROFILE #85 - LCPROF-85-8FT-WH

Name: LED ALUMINUM PROFILE #85 - LCPROF-85-8FT-WH
Brand: LEDCO
SKU: LCPROF-85-8FT-WH
Price: 41.97 CAD
Availability: InStock

SKU: LCPROF-85-8FT-WH

Brand: LEDCO

Give your LED strips the clean, finished look they deserve with the LED Aluminum Profile #85 in white, 8 feet long. Known by plenty of names — aluminum extrusion, LED aluminum channel, extruded aluminum track or simply aluminum profile for LED strip lighting — this is the housing that turns a bare roll of tape light into real architectural lighting. It holds the strip straight, protects it from dust and knocks, helps pull heat away from the diodes, and hides that row of visible dots behind a proper lens. Use it under cabinets, along coves and ceilings, on stair nosings, in closets, behind headboards, on display shelves or under a bar top — anywhere a strip alone would look unfinished.

This profile is extruded from 6063T-5 aluminum, the alloy pros count on for straightness and clean machining, and it comes in a white finish that disappears against white ceilings, crown mouldings and cabinetry. Outside dimensions are compact: 19.4 mm (0.767") wide by 16.4 mm (0.646") tall, with a 13.2 mm (0.519") channel opening that accommodates and protects the majority of our LED strips, including white and coloured RGB and RGBW tapes. It is supplied in an 8-foot length, can be installed indoors or outdoors, can be painted to match your decor, and is certified for the Canadian market. It is backed by a 3-year warranty, and custom fabrication is available up to 192 inches.

Contractors reach for this extrusion on kitchen renovations, basement coves, retail display cases, office reception desks, restaurant bars, stairwells and workshop benches — and because it can be surface-mounted, suspended or simply glued to a surface, it adapts to drywall, wood, melamine and metal alike. The SKU is LCPROF-85-8FT-WH. Need a longer run with fewer joints? Look at the LED aluminum profile #85 in 16 ft white, or the LED aluminum profile #85 in 8 ft plain aluminum for a natural finish. Measure your run, pick your lens, and give your LED strips a professional home.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-85, LCENDCAP-STAND-85-BK, LCENDCAP-STAND-85-H, LCENDCAP-STAND-85-H-BK, LCENDCAP-STAND-85-H-WH, LCENDCAP-STAND-85-WH
Lens: LCLENS-FROS85-8FT, LCLENS-FROS85-8FT-P88, LCLENS-OPAQ85-16FT-BK, LCLENS-OPAQ85-8FT-BK

Built from 6063T-5 aluminum
The 85 Series extrusion is made from 6063T-5 aluminum, a structural alloy chosen for straight runs, crisp edges and consistent channel tolerances. That matters when you are butting several lengths end to end along a ceiling cove: the profile stays true, the lens seats evenly, and the finished line of light reads as one continuous detail instead of a series of segments. Aluminum also does quiet work behind the scenes as a heat sink, drawing warmth away from the tape and helping your LED strip lighting hold its colour and brightness over the years. The white finish blends into painted ceilings, gyprock, white shaker cabinets and MDF trim, and if your colour is a custom one, the profile can be painted to match your decor.

Technical specifications
SKU: LCPROF-85-8FT-WH
Series: Aluminum Profile 85 Series
Material: 6063T-5 aluminum
Finish: WH – Aluminum White
Length: 8 feet
Overall width: 19.4 mm (0.767")
Overall height: 16.4 mm (0.646")
Channel opening: 13.2 mm (0.519")
Also available in: 16 foot length
Custom fabrication: up to 192 inches
Installation: indoor or outdoor
Certification: certified for the Canadian market
Warranty: 3 years

Installation and mounting options
This LED aluminum channel is designed to be easy to install, whichever way your project goes: it can be surface-mounted with screws, suspended, or glued directly to a surface for quick, fastener-free runs on melamine or glass shelving. The ordering guide for the 85 Series lets you specify the pieces that finish the job — lens in opaque or black, standard or swivel mounting, and endcaps with no hole, with hole, or one of each so the low-voltage lead exits cleanly at one end. A tip from the field: dry-fit your full run first, mark your mounting points every few feet, then feed the strip and snap the lens on last so you never scratch it during installation. For runs longer than 8 feet, join sections end to end and keep your power feed and any splices at the endcap with the hole.

Strip compatibility and applications
The 13.2 mm channel accommodates and protects the majority of our LED strips, in single-colour white as well as RGB and RGBW colour-changing tapes, so you can use the same extrusion family across a whole job. Concrete examples: undercabinet lighting in a kitchen, a perimeter cove in a basement family room, toe-kick and vanity lighting in a bathroom, closet shelving, stair nosings, retail display cases and jewellery showcases, reception desks, restaurant bars and back-bar shelving, workshop benches and garage work zones. Because the profile is rated for indoor or outdoor installation and certified for the Canadian market, it also earns its place on covered porches, soffits and patio structures where a bare strip would not survive a season.

Related products and documentation
Same profile, different formats: the LED aluminum profile #85 16 ft white cuts down on joints in long corridors, the LED aluminum profile #85 16 ft white with opaque lens arrives with the diffuser included, and the LED aluminum profile #85 16 ft black is the pick for dark ceilings and industrial interiors. The technical PDF spec sheet, with the full technical drawing and the ordering guide for colour, lens, mounting and endcap, is available in the Documentation tab of this page — download it before you order so your configuration is exactly right the first time.
