NEON FLEX 8W/M - CABINET - LCLS24VFLX-CAB-8W-30K-30M

Name: NEON FLEX 8W/M - CABINET - LCLS24VFLX-CAB-8W-30K-30M
Brand: LEDCO
SKU: LCLS24VFLX-CAB-8W-30K-30M
Price: 1019.97 CAD
Availability: InStock

SKU: LCLS24VFLX-CAB-8W-30K-30M

Brand: LEDCO

Turn every cabinet, shelf and display case into a warm ribbon of light with this ultra-compact LED neon flex made for cabinetry. Often searched as flexible LED neon rope light, led flex neon, neon led or simply cabinet LED strip, this 8W/m cabinet flex neon (SKU LCLS24VFLX-CAB-8W-30K-30M) replaces the dotted, uneven look of ordinary tape light with one continuous, glowing line. Its tiny 10 mm x 10 mm silicone body slips into the slimmest of spaces: kitchen cabinet undersides, glass display cases, millwork, bar backs, closets, bathroom vanity cabinets and custom furniture. Sold as a 30 m roll with free cutting, it lets you light a full kitchen, a retail counter run or an entire showroom from one reel.

Built for clean results, this LED neon flex runs on 24V DC and draws only 8 W per metre while delivering 420 lm/m, so you get a genuinely useful working light without heat or glare hot spots. The 3000K colour temperature gives that warm, welcoming white that flatters wood, quartz and painted doors, and a CRI greater than 80 keeps food, fabrics and merchandise looking true. With 130 LEDs per metre, the diodes blend into a smooth line instead of visible dots, and the flexible silicone jacket with side flanges quietly hides small installation imperfections along the mounting surface. Dimensions are a discreet 10 mm x 10 mm (0.39" x 0.39"), free cut, and the product is backed by a 3-year warranty.

This cabinet neon flex shines wherever the light source should disappear and only the glow remains: under upper kitchen cabinets, inside pantry and closet shelving, along jewellery and bakery display cases, under floating vanities, in reception desks, wine cellars and cove details in Canadian homes, condos and small shops. Contractors love it for renovation work because the small profile fits existing millwork without rebuilding it. Need a different look or output? Compare it with the Flex neon anti-glare 10x10mm 9.6W, the slimmer Neon flex 9.6W/m 3x6mm or the Flex neon 6W/m 6x6mm. Roll out your line of light and give your cabinets the finish they deserve.

Construction and design
This LED neon flex is built on a flexible silicone body measuring only 10 mm x 10 mm (0.39" x 0.39"), with side flanges that sit against the mounting surface. Those flanges are the detail installers appreciate: they mask small imperfections along the run and keep the light line looking crisp even when the substrate is not perfect. The silicone diffuses the diodes into a solid, seamless glow, which is exactly what you want in a cabinet where the light source sits close to the eye. Free cutting means you size each run to the cabinet, the shelf or the display case instead of forcing your layout to match a fixed length.

Light quality
With 130 LEDs per metre, there are no visible dots and no scalloped shadows on the counter below. The 3000K warm white creates a comfortable, hospitality-style ambiance, while a CRI above 80 renders wood grain, stone veining, food and merchandise colours honestly. Output is 420 lm/m for a draw of only 8 W/m, a combination that gives real task light under upper cabinets while using a fraction of the energy of halogen puck lights — with none of their heat inside closed cabinetry.

Technical specifications
SKU: LCLS24VFLX-CAB-8W-30K-30M
Input voltage: 24V DC
Power: 8 W/m
Luminous flux: 420 lm/m
Colour temperature: 3000K
CRI: >80
LED density: 130 LEDs/m
Dimensions: 10 mm × 10 mm (0.39" × 0.39")
Cutting: free cut
Warranty: 3 years

Electrical and installation
Because it operates on 24V DC, this cabinet neon flex needs a low-voltage LED driver sized for the total length you install: add up the metres, multiply by 8 W/m, and choose a driver with comfortable headroom. Low voltage also makes it friendlier to work with inside furniture and millwork, and lets you route long runs with fewer worries. Plan the driver location in an accessible, ventilated spot such as a cabinet gable or a service cavity, respect the manufacturer's cut marks when you shorten a run, and seal any cut end properly before powering up. Mount the flex so the emitting face points toward the counter or shelf rather than toward the user, and the glare simply disappears.

Applications, alternatives and documentation
Kitchen cabinet undersides, pantry and closet shelving, glass display cases in jewellery and bakery shops, floating bathroom vanities, reception desks, bar backs, wine cellars and custom furniture all suit this format. In a Canadian kitchen renovation, one 30 m roll typically covers an entire upper-cabinet layout with cut lengths to spare. If you need a wider profile or a different colour temperature, look at the Flex neon anti-glare white 10x10mm, the ultra-slim Flex neon 3x6mm 9.6W 40K or the Neon flex 6W/m 6x6mm. The full technical PDF (LCLS24VFLX-CAB-8W-30K-30M Spec Sheet) is available in the Documentation tab for your specs, submittals and installation planning.
