NEON FLEX 14.4W/M - SIDE VIEW - LCLS24VFLX-SV-14W-35K

Name: NEON FLEX 14.4W/M - SIDE VIEW - LCLS24VFLX-SV-14W-35K
Brand: LEDCO
SKU: LCLS24VFLX-SV-14W-35K
Price: 140.97 CAD
Availability: InStock

SKU: LCLS24VFLX-SV-14W-35K

Brand: LEDCO

Give your project that hand-bent glass tube look without the fragility: this LED neon flex is the flexible, side-bending light line designers reach for when they want a continuous, dot-free glow. Known under many names — flexible LED neon rope light, led flex neon, neon led, LED flex for signs or simply neon sign LED — it is a silicone-style light strip that bends sideways, so you can trace letters, logos, arches, curved bulkheads and ceiling coves without breaking the beam. Model LCLS24VFLX-SV-14W-35K is the side view version, the one you want when the light has to follow a horizontal curve rather than an up-and-down one: storefront signage, custom lettering, backlit bars, stair rails, garage perimeters and cove lighting all become simple to draw.

This is a 24V DC neon flex delivering 14.4W per metre with 140 LEDs per metre, an efficiency of 120 lm/W and a very high CRI 90, so wood, paint, skin tones and merchandise stay true instead of looking washed out. The PCB measures 8 mm wide, the maximum run is 5 m and the cut size is every 50 mm, which gives you precise control over each segment. It is dimmable, rated IP66 against dust and water jets, and built for 50 000+ hours of service. It also meets IEC 62471 for eye safety, EN 62031 and IEC 60598-1 for protection class, EN 55015 for radio disturbance, plus RoHS and CE compliance — a serious spec set for a product that looks this decorative.

From a Montréal restaurant sign to a basement home theatre in Calgary, this neon flex handles indoor accents and sheltered outdoor work alike, and its low-voltage 24V supply makes it friendly for renovators, contractors and small businesses. Because it is sold as a family, you can match colour temperatures across a whole project with the Flex Neon 14.4W/m side view 2700K, the Neon Flex 14.4W/m side view 3000K or the Flex Neon 14.4W/m side view 4000K. Mounting is handled by the LCBRACK-FLEX-SV accessory kit for 6.5 x 11 mm side view neon, sold in a pack of 2. Sketch your shape, cut, mount, and let the glow do the talking.

Built to bend, built to last
Where traditional glass neon cracks, chips and needs a specialist to repair, this LED neon flex bends by hand and keeps a perfectly even line of light. The side view construction means the strip flexes laterally, which is exactly what sign makers and cabinet shops need to shape letters, script logos, rounded corners and curved coves without kinking the emitting face. With 140 LEDs per metre packed behind a diffusing body, you get a continuous ribbon of light instead of visible dots — the effect people are actually looking for when they search led neon lights or led flex sign.

Light quality you can trust
A CRI of 90 puts this neon flex well above ordinary decorative rope light. Colours in a retail display, the grain of a walnut bar top, a painted feature wall or the skin tones in a barbershop mirror all read naturally. The efficiency of 120 lm/W means you get generous output for the 14.4W each metre draws, so long runs stay reasonable on the electrical side while still reading clearly, even in a room with daylight coming in.

Technical specifications
SKU: LCLS24VFLX-SV-14W-35K
Type: Flex neon side view
Voltage: 24V DC
Power: 14.4W/m ±10%
LEDs per metre: 140 pcs
Efficiency: 120 lm/W
CRI: 90
PCB width: 8 mm
Maximum length: 5 m
Cut size: 50 mm
Dimmable: Yes
Protection rating: IP66
Lifespan: 50 000+ hours
Eye safety: IEC 62471
Protection class: EN 62031, IEC 60598-1
EMC / radio disturbance: EN 55015
RoHS: Yes
CE: Yes

Wiring, cutting and installation
Plan each run around the 5 m maximum length and feed it from a 24V DC low-voltage supply sized for the total wattage of your job (14.4W per metre, plus a comfortable margin). Cut only on the marked 50 mm increments so the circuit stays intact, then seal and connect the end according to the accessory kit instructions. The IP66 rating means dust-tight operation and resistance to water jets, so it holds up in a garage, a covered patio, a car wash bay or a commercial kitchen surround as well as in a dry living room cove. Being dimmable, it pairs with a compatible 24V dimming system when you want a bar or restaurant to shift from bright service mode to a soft evening glow. For mounting, the LCBRACK-FLEX-SV accessory kit is made specifically for 6.5 x 11 mm side view neon and comes in a pack of 2.

Applications, family and documentation
Think channel letters and window signage for a storefront, backlit shelving in a boutique, a glowing handrail in a stairwell, a perimeter line around a garage ceiling, a curved cove in a condo living room, or branding behind a reception desk. Need another colour temperature for the same shape? The same side view profile is available as Flex Neon 14.4W/m side view 2700K, Neon Flex 14.4W/m side view 3000K and Flex Neon 14.4W/m side view 4000K. For slimmer top-bend details, look at the Neon Flex 9.6W/m 3x6mm. The full technical PDF (LCLS24VFLX-SV-14W-35K Spec Sheet) is in the Documentation tab with the dimensional drawing and the complete list of certifications.

Technical Files
