3.5" LUNA LED ROUND REGRESSED GIMBAL RECESSED FIXTURE - RA35-12RG-90BN

Name: 3.5" LUNA LED ROUND REGRESSED GIMBAL RECESSED FIXTURE - RA35-12RG-90BN
Brand: LITELINE
SKU: RA35-12RG-90BN
Price: 86.97 CAD
Availability: InStock

SKU: RA35-12RG-90BN

Brand: LITELINE

Say goodbye to flat, glary ceilings. The 3.5" LUNA LED Round Regressed Gimbal Recessed Fixture (SKU RA35-12RG-90BN) is the little aimable pot light that does the work of three: a compact LED recessed downlight with a tilting, deep-set gimbal that lets you point light exactly where you want it, and an on-fixture colour selectable switch that lets you change the mood without changing the fixture. Shoppers looking for round LED lights, adjustable recessed lighting, eyeball downlights or directional LED pot lights land here for a reason — this one is small in diameter, big on control, and finished in a warm, low-key Brushed Nickel that suits both modern and traditional interiors. Use it for general ceiling lighting, art and feature walls, kitchen islands, sloped ceilings and accent runs in homes, shops and offices.

Under the hood, the LUNA runs on a 12 watt (300mA) dimmable Class II electronic LED driver with 100-135V AC, 50/60Hz input, delivering up to 1160 lumens and up to 102 lumens per watt — real efficiency, and a huge step down in energy use from halogen. Colour selection happens right at the fixture: 2700 K, 3000 K, 3500 K, 4000 K and 5000 K, with output of 1040 lm at 2700 K, 1090 lm at 3000 K, 1135 lm at 3500 K, 1160 lm at 4000 K and 1145 lm at 5000 K. A typical CRI of 95+ makes skin tones, wood grain and paint colours look true, while the regressed lens throws a tight 38° beam with 40° of tilt (20° each way). Dimming runs 100%-10% on standard forward/reverse-phase TRIAC/ELV dimmers. It is cETLus certified, ENERGY STAR qualified, suitable for wet locations, approved for direct contact with insulation, airtight, rated for -20°C~40°C, projected at 70% @ 50,000 hrs, power factor >0.90, and backed by a Lifetime warranty.

With a Ø 3 5/8" (92mm) hole cut, this fixture slips into tight ceilings, soffits, hallways, bathrooms, covered porches and retail displays where a bigger can simply won't fit — and the wet location plus insulated-ceiling approval makes it a smart pick for Canadian homes where showers, entries and exteriors all need to stay sealed and warm. Pair it with matching Brushed Nickel LUNA fixtures like the 3.5" Luna LED round recessed fixture RA35-12F-27K-90BN for a consistent ceiling layout, or explore the same gimbal in other finishes with the 3.5" Luna LED round regressed gimbal fixture RA35-12RG-90BK and 3.5" Luna LED round regressed gimbal fixture RA35-12RG-90WH. Add it to your project list and light your space the way you actually live in it.

Built to last, built to breathe
The LUNA Designer Series starts with a durable airtight aluminum body and an adjustable regressed gimbal, so the LED sits deep inside the trim instead of staring back at you. An anodized blue heat sink maximizes airflow around the LED light source, which is exactly what keeps output and colour stable over the long haul — a projected life of 70% @ 50,000 hrs. The 40° tilt (20° in each direction) lets you aim the beam at a backsplash, a fireplace or a gallery wall, and the regressed optic keeps the bright spot out of your eyes when you're seated under it. The RA35-12RG-90BN ships in a Brushed Nickel trim finish; the same platform is also offered in Black, White and Oil Rubbed Bronze.

Light quality you can see
This is a general application luminaire with an LED module that maintains uniform intensity, producing up to 1160 lumens with a typical CRI of 95+. The on-fixture colour selectable switch covers five colour temperatures — 2700 K, 3000 K, 3500 K, 4000 K and 5000 K — so one SKU covers a warm living room and a crisp workspace. Measured output by setting: 1040 lm at 2700 K, 1090 lm at 3000 K, 1135 lm at 3500 K, 1160 lm at 4000 K and 1145 lm at 5000 K, up to 102 lumens per watt. The lens delivers a 38° beam spread, tight enough to accent, wide enough to layer into a full ceiling plan.

Wiring, driver and dimming
The extruded aluminum hardwire box houses a 12 watt (300mA) dimmable Class II electronic LED driver with 100-135V AC input and a power factor >0.90. An 18" FT6 rated cable with a DC 2.1 connector links the driver to the fixture and is approved for use in plenums and suspended ceilings. Three Quick Connect push-in terminals make wiring fast on site, and two spring loaded clips let the housing mount to virtually any ceiling material. Dimming runs from 100% down to 10% using industry standard forward-phase / reverse-phase TRIAC/ELV dimmers (contact factory for the list of compatible dimmers). Cut a Ø 3 5/8" (92mm) hole and you're in business.

Technical specifications
Application: Ceiling Recess Mount
Approved Location: Wet / Insulated Ceilings
Beam Angle: 38°
CCT (colour selectable): 2700 K / 3000 K / 3500 K / 4000 K / 5000 K
Certification: cETLus
Class II: Yes
CRI: 95+
Dimming: Yes, 100%-10%
Dimming Tech: Forward/reverse-phase TRIAC/ELV
ENERGY STAR: Yes
Hole Cut: Ø 3 5/8" (92mm)
Input: 100-135V AC, 50/60Hz
Lumens: Up to 1160
Lumens per Watt: Up to 102
Operating Temperature: -20°C~40°C (-4°F~104°F)
Power Factor: >0.90
Projected Life: 70% @ 50,000 hrs
Tilt: 40°
Trim Finish: Brushed Nickel (BN)
Wattage: 12W
Warranty: Lifetime

Where it works, and what goes with it
Because it's airtight, approved for direct contact with insulation and suitable for wet locations, this recessed downlight is at home in bathrooms and showers, over kitchen sinks, in mudrooms and covered entries, and across insulated Canadian ceilings where an air seal matters as much as the light itself. Contractors use it for condo retrofits and basement finishes; retailers aim it at merchandise and signage; designers line it up over islands and hallways. Accessories are sold separately and include pre-mounting and new construction plates for 3 1/2" LUNA LED fixtures (P-3520, P-3520NC, P-3524), the P-NCMK-1 new construction mounting kit with hanger bars, brackets and screws, vapour barrier extenders VBE-1 through VBE-5 for new construction and remodel work, and Brushed Nickel reducer ring RA35-XLRING-BN. To keep a room visually consistent, mix this gimbal with fixed LUNA trims such as the 3.5" Luna LED round recessed fixture RA35-12G-90WH, or step up to dim-to-warm with the 3.5" Luna LED regressed gimbal fixture RA35-12RG-DTW90BN. The full technical PDF (RA35-12RG-90BN Spec Sheet) is in the Documentation tab with dimensions, the ordering guide and the complete accessory list.
