3.5" LUNA LED ROUND RECESSED FIXTURE - RA35-12F-27K-90BK

Name: 3.5" LUNA LED ROUND RECESSED FIXTURE - RA35-12F-27K-90BK
Brand: LITELINE
SKU: RA35-12F-27K-90BK
Price: 73.97 CAD
Availability: InStock

SKU: RA35-12F-27K-90BK

Brand: LITELINE

Small aperture, big impact: the LUNA 3.5" round LED recessed fixture from LITELINE (model RA35-12F-27K-90BK) is the discreet pot light renovators keep coming back to. Known by many names — LED downlight, recessed downlight, round LED light, ceiling recess mount fixture — this fixed downlight hides its hardware above the ceiling and leaves only a clean black ring in view. It is built for retrofit work, which means you can bring a modern, even wash of light to a hallway, a kitchen island run or a whole open-plan floor without tearing the ceiling apart, and it drops into new construction just as easily with the right plate or mounting kit.

Under that airtight fixed aluminum body sits a 12 W LED module delivering up to 600 lumens at 57 lumens per watt, with a typical CRI of 90 so wood grain, paint colours, skin tones and food look the way they should. The 38° beam spread keeps light controlled and glare low, and an anodized blue heat sink pulls heat away from the LED for a projected life of 70% at 33,000 hours, backed by a lifetime warranty. It runs on 100-135V AC, 50/60 Hz through a 300 mA dimmable class II electronic driver, is dimmable with industry standard TRIAC/ELV dimmers, carries cETLus certification, LM79 and LM80 data, a power factor greater than 0.90, and is rated for wet locations and direct contact with insulation. Hole cut is Ø 3 5⁄8" (92 mm), operating range -20°C to 40°C (-4°F to 104°F), finished in black.

It shines in kitchens, bathrooms and showers, covered porches, basements, condo corridors, boutiques, cafés and clinics — anywhere Canadian ceilings need a small, tidy, insulation-friendly recessed LED light that handles humidity and cold entryways. Two spring-loaded clips grip virtually any ceiling material, and three quick connect push-in terminals make wiring fast. Prefer the same fixture in another finish or a tiltable head? See the 3.5" Luna LED round recessed fixture RA35-12F-27K-90BN or the 3.5" Luna LED round regressed gimbal recessed fixture RA35-12RG-90BK. Plan your layout and order your LUNA downlights today.

Built to last, built to install fast
The LUNA 3.5" uses a durable airtight fixed aluminum body with an anodized blue heat sink that maximizes airflow around the LED light source — the detail that keeps light output stable year after year in an enclosed, insulated ceiling. Mounting is handled by two spring-loaded clips that attach to virtually any ceiling material, so drywall, plaster and thin panels are all fair game. The recessed LED downlight measures 4 3⁄8" (111 mm) and 3 3⁄8" (85 mm) across the trim and body, with a 15⁄16" (34 mm) profile detail, and requires a Ø 3 5⁄8" (92 mm) hole cut — an easy template to repeat across a long hallway or an open kitchen.

Light quality you can see
A 12 watt LED module maintains uniform intensity and produces up to 600 lumens with a typical CRI of 90, so colours stay honest under the beam: countertop veining, cabinet finishes, artwork and merchandise all read correctly. The lens delivers a controlled 38° beam spread, ideal for spacing downlights evenly without hot spots or harsh glare, and the fixture is offered in a 3000 K colour temperature for a clean, comfortable white. Efficiency lands at 57 lumens per watt with a power factor greater than 0.90, and performance is documented through LM79 and LM80 testing.

Electrical, dimming and installation
Power comes from an extruded aluminum hardwire box housing a 300 mA dimmable class II electronic LED driver with 100-135V AC input. An 18" (457 mm) FT6 rated cable with a DC 2.1 connector links the driver to the fixture and is approved for use in plenums and suspended ceilings — handy for commercial ceilings and condo bulkheads. Three quick connect push-in terminals make wiring quick and tidy. The fixture is dimmable with TRIAC/ELV dimmers; check the manufacturer's compatible dimmer list before pairing controls. It is suitable for wet locations, approved for direct contact with insulation, and operates from -20°C to 40°C (-4°F to 104°F).

Technical specifications
SKU: RA35-12F-27K-90BK
Brand: LITELINE
Application: Ceiling recess mount
Approved location: Wet / insulated ceilings
Wattage: 12W
Lumens: 600
Lumens per watt: 57
CRI: 90
Beam angle: 38°
Input: 100-135V AC, 50/60Hz
Dimming: Yes, TRIAC/ELV
Class II: Yes
Power factor: >0.90
Hole cut: Ø 3 5⁄8" (92mm)
Operating temperature: -20°C~40°C (-4°F~104°F)
Projected life: 70% @ 33,000 hrs
Certification: cETLus
Colour: Black
Warranty: Lifetime

Applications, accessories and documentation
Think kitchens and pantries, bathrooms and shower ceilings, mudrooms, covered entries, stairwells, retail displays, salons, dental offices and restaurant dining rooms — anywhere a small round LED pot light beats a bulky 6" can. Liteline lists accessories sold separately for this family: the P-3520 3 5⁄8" round pre-mounting plate with driver attachment clip and the P-3520NC new construction plate for 3½" LUNA LED fixtures, the P-NCMK-1 new construction mounting kit with hanger bars, brackets and screws, VBE-1 to VBE-4 vapour barrier extenders for new construction and remodel work, and the RA35-XLRING-BK reducer ring in black to match this trim. Within the catalogue you can also compare the 3.5" Luna LED round recessed fixture RA35-12F-30K-90WH, the dim-to-warm 3.5" Luna LED round recessed fixture RA35-12F-DTW-90BK and the adjustable 3.5" Luna LED round regressed gimbal recessed fixture RA35-12RG-90WH. The full technical PDF spec sheet is available in the Documentation tab for dimensions, wiring details and ordering references.
