NEON FLEX 14.4W/M - TOP VIEW - LCLS24VFLX-TV-14W-40K

Name: NEON FLEX 14.4W/M - TOP VIEW - LCLS24VFLX-TV-14W-40K
Brand: LEDCO
SKU: LCLS24VFLX-TV-14W-40K
Price: 127.97 CAD
Availability: InStock

SKU: LCLS24VFLX-TV-14W-40K

Brand: LEDCO

Give any room, storefront or facade that unmistakable glow-tube look — without the fragile glass, the high voltage or the buzzing. This LED neon flex (also searched as led flex neon, flexible LED neon rope light, neon led strip or led flex sign material) is a top-view 10x10 mm silicone-style profile that throws its light straight up from the face of the run, giving you a smooth, continuous line with no visible dots. It's the go-to product for cove lighting, under-cabinet accents, stair nosings, bar fronts, channel letters, neon sign led lettering, gaming rooms, garage perimeters and architectural outlines, indoors or out. SKU LCLS24VFLX-TV-14W-40K.

Under the hood: 140 LEDs per meter at 14.4W/m (±10%) running on safe 24V DC, with an efficiency of 120 lm/W and a high CRI 90 that keeps wood, paint, food and merchandise looking true. This version is a crisp 4000K neutral white — clean and modern without going cold. The PCB is 8 mm wide inside a 10±0.5 mm profile, the maximum run is 5 m per feed, and you can cut it every 50 mm, so it follows your layout instead of forcing you to change it. It's dimmable, rated IP66 against dust and water jets, RoHS and CE compliant, tested to IEC 62471 for eye safety, EN 62031 / IEC 60598-1 for protection class and EN 55015 for radio disturbance, with a lifespan of 50 000+ hours.

From a Montréal condo cove ceiling to a Calgary shop sign, a restaurant bar soffit or a contractor's garage perimeter, this neon LED handles both polished interiors and exposed outdoor runs thanks to its IP66 rating — a real advantage through Canadian rain, snow and washdowns. For clean, straight installs, the accessory kit LCBRACK-FLEX-TV (mounting kit for 10x10 mm top view neon, pack of 2) is made specifically for this profile. Prefer a warmer glow for the same run? The same product is offered in Flex Neon 14.4W/m Top View 2700K, and for slimmer lines you can look at the Neon Flex 9.6W/m 3x6mm or the Flex Neon 6W/m 6x6mm. Map out your run, add a 24V DC driver and start bending light your way.

Built to bend, built to last
This LED neon flex uses a top-view emission design: the diodes face straight out of the 10x10 mm profile so the light exits through the top face in an even band. The diffusing body hides the 140 individual LEDs per meter, which is exactly what you want when the strip is visible in a sign, a cove or along a handrail — no hot spots, no dotting, just a solid line of light. The 8 mm PCB inside keeps the run flexible enough to shape curves, letters and logos, while the sealed IP66 body keeps dust and water jets out of the electronics.

Light quality that flatters everything
At CRI 90, colours stay honest: skin tones in a salon, bottle labels behind a bar, wood grain in a cove ceiling, paint and tile in a bathroom. The 4000K neutral white is the sweet spot for kitchens, garages, workshops, offices and retail — bright and contemporary, but not clinical. With 120 lm/W of efficacy, you get that output while drawing only 14.4W per meter, and since the whole system is dimmable, the same installation can go from full work light to a soft evening glow.

Technical specifications
SKU: LCLS24VFLX-TV-14W-40K
LEDs per meter: 140 pcs
Power: 14.4W/m ±10%
Efficacy: 120 lm/W
Voltage: 24V DC
PCB width: 8 mm
CRI: 90
Colour temperature: 4000K
Maximum length: 5 m
Cut size: 50 mm
Dimmable: Yes
Protection rating: IP66
Lifespan: 50 000+ hours
Compliance: RoHS, CE, IEC 62471 (eye safety), EN 62031 / IEC 60598-1 (protection class), EN 55015 (EMC / radio disturbance)

Wiring and installation
Plan your layout in 50 mm increments — that's the cut size, and cutting anywhere else breaks the circuit. Each feed supports a maximum run of 5 m, so longer perimeters are simply split into multiple 5 m sections fed from the same 24V DC power supply; size the driver to the total wattage (14.4W per meter) and leave headroom. Because it runs on low-voltage 24V, it's friendly for under-cabinet, stair, closet and vehicle-adjacent work. End caps and the proper accessory kit keep the IP66 seal intact at cut points, and the LCBRACK-FLEX-TV mounting kit for 10x10 mm top view neon (pack of 2) is the matching hardware for straight, rattle-free runs on ceilings, soffits and sign backers. For dimming, use a control compatible with your 24V DC driver.

Where to use it, and what goes with it
Think cove ceilings in condos and living rooms, toe-kick and under-cabinet kitchen lighting, bar and reception desk fronts, retail display shelving, stair and corridor accents, gym and garage perimeters, restaurant and café signage, channel letters and custom neon sign led lettering, plus outdoor facade and soffit outlines where IP66 earns its keep. Within the same family you can mix formats: the Flex Neon 14.4W/m Top View 2700K for warm zones, the compact Flex Neon 3x6mm 24V 9.6W 40K for tight reveals, or the Flex Neon anti-glare 10x10mm 24V 9.6W 30K 20M when sightlines matter. Full details, dimensions and tolerances are in the technical PDF (LCLS24VFLX-TV-14W-40K Spec Sheet) in the Documentation tab.
