NEON FLEX 14.4W/M - SIDE VIEW - LCLS24VFLX-SV-14W-35K-30M

Name: NEON FLEX 14.4W/M - SIDE VIEW - LCLS24VFLX-SV-14W-35K-30M
Brand: LEDCO
SKU: LCLS24VFLX-SV-14W-35K-30M
Price: 828.97 CAD
Availability: InStock

SKU: LCLS24VFLX-SV-14W-35K-30M

Brand: LEDCO

Draw a glowing line anywhere you want it: this LED neon flex is the flexible neon rope that bends sideways to follow curves, corners, letters and coves without a single dark spot. Known on jobsites as neon flex, flex neon, LED neon lights, flexible LED neon rope light or LED flex sign material, this side-view version (SKU LCLS24VFLX-SV-14W-35K-30M) bends flat, on its side, so you can write names, draw logos, trace a staircase or run a continuous halo of light around a ceiling. It comes as a long roll to cut on site, making it the go-to solution for neon sign LED projects, cove lighting, under-cabinet accents, gym and garage feature walls, bar fronts and storefront signage — residential and commercial alike.

Under the silicone jacket, 140 LEDs per meter create a smooth, dot-free line of light at 14.4 W per meter (±10%) and an efficient 120 lm/W. It runs on 24V DC, has an 8 mm PCB, measures 11 ±0.5 mm on the light face and is dimmable, so you can set the mood from full brightness down to a soft glow. A CRI of 90 renders wood, paint, skin tones and merchandise beautifully — exactly what you want above a kitchen island or in a retail display. The rated IP66 protection code handles dust and water jets, and the rating list includes RoHS, CE, IEC 62471 eye safety, EN 62031 / IEC 60598-1 protection class and EN 55015 for radio disturbance. Expect 50 000+ hours of service, with a max run of 5 m per feed and a clean cut size of 50 mm.

This flex shines in modern kitchens and basements, hallway coves, stairwell nosings, home theatres, gyms, restaurants, salons, offices and shop windows — anywhere a Canadian renovation calls for a crisp lit line instead of a visible fixture. Because it bends sideways, it is the right profile for flat-mounted curves and lettering where a top-view strip would kink. Mount it fast and straight with the LCBRACK-FLEX-SV accessory kit for 6.5 x 11 mm side view neon (pack of 2). Need a different white? The same side view profile is offered in Flex neon 14.4W/m side view 2700K, Neon flex 14.4W/m side view 3000K and Flex neon 14.4W/m side view 4000K. Roll out your line of light and make the room unforgettable.

Built to bend, built to last
This LED neon flex is a continuous silicone-jacketed light line with a 8 mm PCB inside and a light face of 11 ±0.5 mm, engineered for side bending. That side-view geometry is what lets you lay the flex flat on a surface and curve it left and right — the shape you need for script lettering, logos, rounded coves and serpentine runs. With 140 LEDs per meter, the diodes are packed tight enough that the diffuser reads as one solid glowing tube instead of a row of dots, which is exactly why designers specify neon flex over an exposed LED strip.

Light quality you can trust on camera and in store
A CRI of 90 means colours stay honest: cabinet finishes, brick, plated food, clothing and skin tones all look natural under it, a real advantage for restaurants, salons, boutiques and content-creation walls. Efficiency sits at 120 lm/W for 14.4 W per meter (±10%), and the product is dimmable, so the same run can be a bright working accent by day and a soft ambience at night when paired with a compatible 24V dimming system.

Technical specifications
SKU: LCLS24VFLX-SV-14W-35K-30M
LEDs per meter: 140 pcs
Power: 14.4W/M (±10%)
Efficacy: 120 lm/W
Voltage: 24V DC
PCB width: 8 mm
CRI: 90
Max length: 5 m
Cut size: 50 mm
Dimmable: Yes
Protection code rating: IP66
Lifespan: 50 000+ hours
RoHS: Yes
CE: Yes
Eye security: IEC 62471
Protection class: EN 62031 IEC 60598-1
EMC / radio disturbance: EN 55015

Electrical and installation notes
Everything runs on 24V DC, so plan a low-voltage power supply sized for your total load: multiply 14.4 W by the number of meters you are feeding and keep headroom. Respect the maximum length of 5 m per feed — longer layouts are simply split into sections fed from the same supply to avoid voltage drop and keep brightness even end to end. Cut only at the marked 50 mm cut points, then seal and connect the section properly before powering up. The IP66 protection code rating means the flex resists dust and water jets, which is reassuring for covered patios, car ports, garages and wash-down commercial areas. For clean, repeatable mounting on flat surfaces and curves, use the LCBRACK-FLEX-SV accessory kit designed for 6.5 x 11 mm side view neon, sold in a pack of 2.

Applications, family and documentation
Think perimeter cove in a finished basement, a lit line under a floating vanity, a glowing handrail in a stairwell, a brand name behind a reception desk, a gym mirror wall, a bar back, or storefront signage that still reads at dusk — classic LED flex sign and flexible LED neon rope light territory. The same side view profile is available in other whites: Flex neon 14.4W/m side view 2700K for warm residential spaces, Neon flex 14.4W/m side view 3000K and Flex neon 14.4W/m side view 4000K for crisper commercial light. If you need a slimmer line for tight coves, look at the Neon flex 9.6W/m 3x6mm. The full technical PDF (LCLS24VFLX-SV-14W-35K-30M Spec Sheet) with dimensions and certifications is in the Documentation tab.

Technical Files
