ATK SERIES FOR RESIDENTIAL AND COMMERCIAL APPLICATIONS - ATK06-SL

Name: ATK SERIES FOR RESIDENTIAL AND COMMERCIAL APPLICATIONS - ATK06-SL
Brand: LITELINE
SKU: ATK06-SL
Price: 101.97 CAD
Availability: InStock

SKU: ATK06-SL

Brand: LITELINE

Give your room the freedom to point light exactly where you want it. The ATK06-SL is a 6-foot single circuit extruded aluminum track in a Silver finish from LITELINE, the backbone of any track lighting system for homes, shops and offices. People search for it as a lighting track, track rail, track bar or simply as the part that LED track heads clip into — and that is exactly what it is: the powered channel that carries your track fixtures, lets you slide them along the run and aim them at artwork, counters, shelving or a kitchen island.

Part of the ATK series, this track is constructed of 0.06" extruded aluminum with a PVC bus bar support holding 12 gauge round bus bars, so the conductors stay protected and the section keeps a clean, low profile against the ceiling. A polarity groove on the face of the track marks the location of the grounding conductor, which makes wiring quick and mistake-free. The single circuit power distribution system carries single hot and neutral conductors rated for a maximum capacity of 20 Amps (2400 watts per circuit) at 120V, giving you plenty of room to add heads as the project grows. The extrusion measures 5⁄8" (16mm) by 1 3⁄8" (35mm) in section, it is surface mounted with the supplied mounting hardware, and suspended mounting is available with accessories ordered separately. It is cULus listed and backed by a 5 Years warranty.

This 6' section is a favourite in Canadian condos, renovated basements, galleries, boutiques, cafés, salons and small commercial lighting jobs where one straight run does the whole job. It works with all A-Line and Juno style track fixtures, accessories and connectors, so you can pair it with heads such as the 8.5W LED track head ATF7509-DTW-38-BK or the 8.5W LED track head ATF7509-DTW-38-WH. Need another finish or a shorter run? See the ATK06-BK in black or the ATK04-BN 4-foot track. Plan your run, add your feed and connectors, and start aiming light where it counts.

Built to last, built to disappear
The ATK series is an extruded aluminum track designed for use with A-Line track fixtures, available in 2', 4', 6', 8' and 12' nominal lengths. This SKU is the 6' version in Silver. The extrusion is 0.06" aluminum, with a PVC bus bar support holding 12 gauge round bus bars, and the copper electrical conductors are concealed in a thermo-plastic, low-profile track section. The result is a lighting track that reads as a slim architectural line on the ceiling rather than a piece of equipment, with a Silver finish that blends nicely with stainless appliances, aluminum window frames and modern metal accents.

Electrical and safety details
This is a single circuit power distribution system designed to supply lighting units flexibly. Single hot and neutral conductors are rated for a maximum capacity of 20 Amps (2400 watts per circuit) at 120V, which leaves generous headroom for a full row of LED heads on one run. A polarity groove located on the face of the track indicates the location of the grounding conductor, so the installer always knows which way the section is oriented before the feed goes on. The product is cULus listed, and it carries a 5 Years warranty.

Technical specifications
SKU: ATK06-SL
Brand: LITELINE
Series: ATK, single circuit extruded aluminum track
Nominal length: 6'
Colour: SL – Silver
Section: 5⁄8" (16mm) x 1 3⁄8" (35mm)
Extrusion: 0.06" extruded aluminum
Bus bars: 12 gauge round, PVC bus bar support
Voltage: 120V
Capacity: 20 Amps, 2400 watts per circuit
Mounting: surface mounted with supplied hardware; suspended with accessories ordered separately
Labels: cULus listed
Warranty: 5 Years

Installation and compatibility
The track is surface mounted using the supplied mounting hardware, and suspended mounting is available with accessories ordered separately, such as the RODR 12" hollow stem rod, the RODF hollow suspension rod kit, the ATKA250 4.75" sloped ceiling canopy kit, or aircraft cable kits like the ATKM420 and ATKM421. Feeds and connectors are also ordered separately: ATKP09 live end power feed, ATKP10 wired end power feed with 15' plug-in cord, ATKP02 'L' and 'I' feed, ATKP03 'T' feed, ATKP04-1C 'X' feed, ATKC01 'I' connector and ATKC05 flexible connector let you turn corners and join sections into longer runs. The system is compatible with all A-Line and Juno style track fixtures, accessories and connectors, including APOLLO LED, SORA LED, ATLAS, DELTA, FLEX, FOCUS, TEARDROP, DINE and Flight LED track heads — for example the ATF7509-DTW-38-WH track head.

Where it earns its keep, and what to read next
A single 6' run lights a kitchen island, a hallway of framed photos, a home office desk or a retail display wall; two or three sections joined with connectors handle a boutique, a café, a salon, a showroom or an office reception where commercial LED lighting has to be re-aimed as displays change. Matching the run to the finish of the room is easy: this Silver version has siblings in the ATK06-BN brushed nickel and ATK06-WH white versions. The full technical PDF (ATK06-SL Spec Sheet) is in the Documentation tab, with the technical drawings, the ordering guide and the complete list of accessories, connectors, power feeds and current limiters — worth printing before you climb the ladder.
