ORBIT 4" ROTATABLE GIMBAL - SCP4S-9W-CCT-BN

Name: ORBIT 4" ROTATABLE GIMBAL - SCP4S-9W-CCT-BN
Brand: LITELINE
SKU: SCP4S-9W-CCT-BN
Price: 37.97 CAD
Availability: InStock

SKU: SCP4S-9W-CCT-BN

Brand: LITELINE

Point your light exactly where it matters. The ORBIT 4" Rotatable Gimbal, model SCP4S-9W-CCT-BN, is a square-trim LED gimbal recessed light — what most people call a pot light, a directional downlight or an adjustable recessed downlight — finished in warm brushed nickel. Its aluminum head turns a full 360° and tilts up to 80°, so a single row of fixtures can wash an art wall, graze a stone fireplace, highlight a kitchen island or simply throw even, comfortable light across a room. Homeowners reach for it during renovations, contractors specify it for retrofit jobs, and shop or office owners use it wherever a fixed downlight just can't aim where the merchandise is.

Behind the clean square trim is a 9 watt LED module delivering up to 1010 lumens — up to 112 lumens per watt — with a beautiful typical CRI of 96 that makes skin tones, wood grain and paint colours look true. A 5-position CCT switch lets you choose between five selectable colour temperatures: 2700 K (868 lumens), 3000 K (927), 3500 K (971), 4000 K (1010) and 5000 K (982), so every room in the house can match without ordering different parts. It runs on 100-135V AC, 60Hz, dims smoothly from 100% to 10% on standard TRIAC/ELV dimmers, and is Class II, Energy Star qualified, Title 24 compliant and cETLus certified, with LM79 and LM80 testing behind it. The hole cut is Ø 4¼" (108 mm), it is airtight, suitable for wet locations, approved for direct contact with insulation, rated for -40°C to 40°C, projected at 70% output at 50,000 hours and backed by a lifetime warranty.

This LITELINE fixture shines in kitchens, hallways, bathrooms and finished basements, on vaulted ceilings and in exterior soffits where Canadian weather demands a wet-location rating — and it works just as well in boutiques, clinics and small offices. Two spring-loaded clips grip any ceiling material, three quick-connect push-in terminals speed up wiring, and a 15" FT6 cable with 3-pin DC connector is approved for plenums and suspended ceilings. Prefer another finish or a round trim? See the Orbit 4" rotatable gimbal in white, the Orbit 4" rotatable gimbal in black, or the round Orbit 4" round gimbal in brushed nickel. Order your Orbit gimbals today and light your project the way you imagined it.

Built to aim, built to last
The ORBIT square gimbal is built around a durable aluminum body with 360° rotation and 80° tilting, so the light source can be redirected long after the ceiling is closed up. The brushed nickel (BN) trim adds a soft metallic accent that blends with stainless appliances and modern hardware, while the compact profile — 4 3⁄16" (106 mm) trim depth dimension, 3 15⁄32" (88 mm) and 4 15⁄16" (125 mm) body dimensions, and a 4¼" (108 mm) hole cut — keeps the fixture discreet in the ceiling plane. It is offered in round and square shapes; this SKU is the square version.

Light quality you can see
The 9 watt LED module maintains uniform intensity and produces up to 1010 lumens through a lens that creates a 36° beam spread — tight enough for accenting, wide enough for general downlighting when fixtures are spaced in a grid. A typical CRI of 96 is well above what most recessed lights offer, which matters in kitchens, bathrooms, retail displays and anywhere colour accuracy counts. The 5-position colour selectable switch covers 2700 K, 3000 K, 3500 K, 4000 K and 5000 K, with measured output of 868, 927, 971, 1010 and 982 lumens respectively, so you can fine-tune warmth room by room from a single box.

Driver, dimming and wiring
Power comes from an extruded aluminum hardwire box housing a 210 mA dimmable Class II electronic LED driver with 100-135V, 60Hz AC input. Three "quick connect" push-in terminals make wiring fast on site, and a 15" FT6 rated cable with a 3-pin DC connector links driver to fixture — approved for use in plenums and suspended ceilings. Dimming runs from 100% down to 10% with industry standard TRIAC/ELV dimmers. Two spring-loaded clips let the housing snap into any ceiling material, making this an easy retrofit in existing 4" openings.

Technical specifications
SKU: SCP4S-9W-CCT-BN
Application: Ceiling Recess Mount
Approved location: Wet / Insulated Ceilings
Beam angle: 36°
CCT: 2700 K / 3000 K / 3500 K / 4000 K / 5000 K
Certification: cETLus
Class II: Yes
Colour: Brushed Nickel
CRI: 96
Dimming: Yes, TRIAC/ELV, 100%-10%
Energy Star: Yes
Hole cut: Ø 4¼" (108 mm)
Input: 100-135V AC, 60Hz
LM79 / LM80: Yes
Lumens: Up to 1010
Lumens per watt: Up to 112
Power factor: 0.95
Projected life: 70% @ 50,000 hrs
Operating temperature: -40°C~40°C (-40°F~104°F)
Title 24: Yes
Warranty: Lifetime
Wattage: 9W

Applications, compatible items and documentation
Because it is airtight, insulation-contact approved and wet location rated indoors and outdoors, this gimbal handles sloped and vaulted ceilings, covered porch and soffit installations, bathrooms with showers, and unheated entries where temperatures drop to -40°C. Picture a new kitchen with 4000 K over the counters and 2700 K in the adjoining dining nook, a basement rec room on a wall dimmer, or a boutique where every gimbal is tilted toward the shelving. Listed accessories, sold separately, include the P-4020 and 24" P-4024 round pre-mounting plates with driver attachment clip, the P-4020NC new construction plate, the P-NCMK-1 new construction mounting kit with hanger bars, brackets and screws, vapour barrier extenders VBE-1 for new construction and VBE-2, VBE-3 and VBE-4 for remodel work, reducer rings RA4-XLRING-BK, RA4-XLRING-BN and RA4-XLRING-WH for 4" fixtures, plus ORBIT-EXT-10-3W 10' and ORBIT-EXT-50-3W 50' flexible FT6 extensions (2 pcs max), and the OnCloud smart Wi-Fi controls LC-CRTL-3WAY-1 3-way switch and LC-CRTL-DIM-1 120V dimmer, compatible with the WiZ App. Mixing trims on one job is easy: pair this SKU with the square Orbit gimbal in black, the square Orbit gimbal in white or the round Orbit 4" round gimbal in white. The full technical PDF spec sheet is available in the Documentation tab for your electrician, inspector or lighting plan.

Technical Files
