ORBIT 4" ROTATABLE GIMBAL - SCP4-9W-CCT-BK

Name: ORBIT 4" ROTATABLE GIMBAL - SCP4-9W-CCT-BK
Brand: LITELINE
SKU: SCP4-9W-CCT-BK
Price: 32.97 CAD
Availability: InStock

SKU: SCP4-9W-CCT-BK

Brand: LITELINE

Point your light exactly where you want it — the LITELINE ORBIT 4" Rotatable Gimbal in black (SKU SCP4-9W-CCT-BK) is the adjustable recessed downlight homeowners, renovators and contractors keep coming back to. Call it a gimbal pot light, a 4-inch directional LED pot light, an adjustable recessed light or a colour-selectable retrofit downlight — it's the same idea: a slim 4" round fixture with a durable aluminum body that gives you 360° rotation and 80° tilt so you can wash a stone fireplace, graze a feature wall, highlight artwork or simply aim light away from a sloped ceiling. It drops into new construction or straight into an existing 4" opening for retrofit work, which makes it a favourite for kitchens, hallways, living rooms, vaulted ceilings, soffits and small commercial spaces where fixed downlights just don't cut it.

Behind the black trim sits a 9 watt LED module delivering up to 1010 lumens — up to 112 lumens per watt — with a 36° beam spread that keeps the light crisp and controlled. The 5-position CCT switch lets you choose 2700 K, 3000 K, 3500 K, 4000 K or 5000 K (868, 927, 971, 1010 and 982 lumens respectively), so one colour selectable fixture covers warm cozy rooms and bright task areas alike. A typical CRI of 96 renders skin tones, wood, paint and merchandise beautifully. It runs on 100-135V AC, 60Hz through a dimmable Class II electronic driver, dims 100%-10% with industry-standard TRIAC/ELV dimmers, and carries cETLus certification, Energy Star, Title 24, LM79 and LM80 data, a 0.95 power factor, a projected life of 70% @ 50,000 hrs and a lifetime warranty. It's airtight, suitable for wet locations, indoor/outdoor rated and approved for direct contact with insulation.

That wet-location rating and a -40°C~40°C operating range make it a smart pick for Canadian realities: covered porches, entry soffits, exposed patios, bathrooms and showers, plus insulated attics where airtight matters. Hole cut is Ø 4 1/4" (108mm), two spring-loaded clips grab any ceiling material, and three Quick Connect push-in terminals make wiring quick. Need a different trim finish? The same gimbal comes in Orbit 4" rotatable gimbal in brushed nickel and Orbit 4" rotatable gimbal in white. Aim, dim, done — add the black Orbit to your lighting plan today.

Built to be aimed
The ORBIT's strength is its movement. A durable aluminum body pivots a full 360° and tilts up to 80°, so after the ceiling is closed you can still fine-tune every beam. That's the difference between a hallway of static surface mount led downlights and a room that actually feels designed — light pushed onto a backsplash, angled down a staircase, or tipped back to level out on a cathedral ceiling. The black trim keeps the aperture visually quiet against dark ceilings, wood planking and industrial-style interiors, while the compact housing (3 15/32" / 88mm deep, 4 15/16" / 125mm wide at the trim, 4 3/16" / 106mm at the body) fits into tight joist bays and shallow bulkheads.

Light quality you can see
A 9 watt LED module produces up to 1010 lumens with uniform intensity and a 36° beam spread for controlled, accent-friendly punch. The 5-position CCT switch gives you 2700 K (868 lumens), 3000 K (927), 3500 K (971), 4000 K (1010) and 5000 K (982) — one colour selectable LED pot light that can be warm in a bedroom and neutral-bright in a laundry room. With a typical CRI of 96, colours stay honest: cabinet stains, paint samples, food on a counter and retail merchandise all read true, which is why this fixture works as well in a boutique as it does in a living room.

Electrical and installation
Power comes from an extruded aluminum hardwire box housing a 210mA dimmable Class II electronic LED driver with 100-135V, 60Hz AC input and a 0.95 power factor. A 15" (381mm) FT6-rated cable with a 3-pin DC connector links driver and fixture and is approved for use in plenums and suspended ceilings. Three "Quick connect" push-in terminals make wiring fast, and two spring-loaded clips let the fixture grab any ceiling material. Hole cut is Ø 4 1/4" (108mm). Dimming runs 100%-10% on industry-standard TRIAC/ELV dimmers, and the fixture is airtight, suitable for wet locations, indoor/outdoor rated, approved for direct contact with insulation and rated for -40°C~40°C (-40°F~104°F) operation.

Technical specifications
SKU: SCP4-9W-CCT-BK
Brand: LITELINE
Application: Ceiling Recess Mount
Approved location: Wet / Insulated Ceilings
Wattage: 9W
Lumens: Up to 1010
Lumens per watt: Up to 112
CCT: 2700 K / 3000 K / 3500 K / 4000 K / 5000 K
CRI: 96
Beam angle: 36°
Input: 100-135V AC, 60Hz
Dimming: Yes, 100%-10%, TRIAC/ELV
Hole cut: Ø 4 1/4" (108mm)
Rotation / tilt: 360° / 80°
Power factor: 0.95
Projected life: 70% @ 50,000 hrs
Certification: cETLus, Energy Star, Title 24, LM79, LM80, Class II
Colour: BK (Black)
Warranty: Lifetime

Applications, accessories and documentation
Think kitchen islands and upper-cabinet grazing, sloped and vaulted ceilings, stairwells, covered entry soffits, bathrooms and showers, basement renovations, plus offices, clinics, cafés and retail displays that need aimable accents instead of flat general light. Accessories are sold separately and include the P-4020 and P-4024 pre-mounting plates, the P-4020NC new construction plate, the P-NCMK-1 new construction mounting kit, VBE-1 through VBE-4 vapour barrier extenders, RA4-XLRING-BK reducer ring for 4" fixtures in black, and the ORBIT-EXT-10-3W and ORBIT-EXT-50-3W flexible FT6 extensions (2 pcs max). For dimming control, the LC-CRTL-DIM-1 OnCloud smart Wi-Fi dimmer (120V) and LC-CRTL-3WAY-1 smart Wi-Fi 3-way switch are listed as compatible accessories. Matching finishes are available as the Orbit 4" rotatable gimbal in brushed nickel and the Orbit 4" rotatable gimbal in white. The full technical PDF spec sheet for SCP4-9W-CCT-BK is in the Documentation tab — download it for dimensions, the CCT/lumen table and the ordering guide before you spec your project.
