LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-LENS-FROS

Name: LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-LENS-FROS
Brand: LEDCO
SKU: LCPROF-90-8FT-LENS-FROS
Price: 55.97 CAD
Availability: InStock

SKU: LCPROF-90-8FT-LENS-FROS

Brand: LEDCO

Renovating a kitchen or fitting out a shop? This LED aluminum profile with frosted lens (LCPROF-90-8FT-LENS-FROS) is the finishing touch that makes strip lighting look professional. From the 90 series, it is an 8-foot aluminum profile for LED strip lighting designed for corner mounting: it holds your strip in the angle between two surfaces and throws the light at 45°. Searched as an LED aluminum channel, an aluminum profile extrusion or a corner LED diffuser, it is a smart solution for cabinets, shelves, display cases and retail stands, in residential and commercial projects.

The profile is made of 6063-T5 aluminum alloy, which increases heat dissipation and increases the lifetime of your LED strip. Its frosted lens softens the light, and the profile design is focused on uniform light without hot spots. The technical drawing shows a compact cross-section of 15.6 mm (0.614 in) by 17.5 mm (0.689 in), and the application guide covers LED strips 10 mm (3/8 in) wide or less. A long lens-fitting system with an enhanced mechanical fit keeps the lens in place year after year, and the 90 series is backed by a 3-year warranty.

In a Halifax kitchen, a Kingston craft room or a Trois-Rivières gift shop, the 8 ft length is easy to transport and cut to size. Want a black finish? Choose the 8 ft black profile with frosted lens. Prefer an opaque lens? See the 8 ft profile with opaque lens, or go long with the 16 ft profile with frosted lens. Start your corner LED lighting project today with a frosted LED profile that looks built-in.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-90, LCENDCAP-STAND-90-BK, LCENDCAP-STAND-90-H, LCENDCAP-STAND-90-H-BK

Light aimed at 45°, not straight down
A flat channel under a cabinet points light straight down. The 90 series corner LED profile is different: mounted in a corner, it offers lighting with a beam oriented at 45 degrees and without hot spots, washing the wall, the counter or the display in front of it. That is why the series excels at maximizing the appeal of products in POP stands while keeping a minimalist style. The LCPROF-90-8FT-LENS-FROS is the 8 ft version with a frosted lens, ideal for kitchen and shelf lighting.

Aluminum that works for your LEDs
The profile is made of 6063-T5 aluminum alloy that increases heat dissipation, and its use increases the lifetime of your LED strip. In other words, this aluminum extrusion is both a housing and a heat sink. The frosted lens gives the light a soft, even look, and the long lens-fitting system with a new, enhanced mechanical fit maximizes long-term durability, so the lens stays put in busy kitchens and shops.

Step-by-step installation
First, choose an LED strip 10 mm (3/8 in) wide or less. Next, measure your corner and cut the profile and frosted lens with a fine-tooth saw, then deburr the edges. The series spec sheet shows a 45° corner bracket and double-face mounting tape for mounting, plus end caps with no hole, with a hole or one of each. Then apply the strip in the clean channel, fit the lens and close the ends, with the wire leaving through an end cap with a hole. Finally, connect a compatible power supply and enjoy the result.

Technical specifications
SKU: LCPROF-90-8FT-LENS-FROS
Series: 90, corner profile
Length: 8 ft
Lens: frosted
Beam orientation: 45°
Cross-section (drawing): 15.6 mm (0.614 in) x 17.5 mm (0.689 in)
LED strip width: up to 10 mm (3/8 in)
Material: 6063-T5 aluminum alloy
Applications: residential and commercial
Warranty: 3 years

Great spots for a corner profile
Try it where the upper cabinets meet the backsplash, along the top corner of a bookcase, inside a craft room cupboard, in a pantry or on the corner of a boutique display. It also works well inside a glass-door cabinet or a home office bookcase. From Victoria to St. John's, this aluminum LED profile is a simple upgrade for LED strip lighting projects. The spec sheet, with the technical drawing and ordering options, is in the Documentation tab. For long corners, pick the 16 ft profile with frosted lens.
