LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-BK-LENS-FROS

Name: LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-BK-LENS-FROS
Brand: LEDCO
SKU: LCPROF-90-8FT-BK-LENS-FROS
Price: 67.97 CAD
Availability: InStock

SKU: LCPROF-90-8FT-BK-LENS-FROS

Brand: LEDCO

Soft light, sharp style: this black LED aluminum profile with frosted lens (LCPROF-90-8FT-BK-LENS-FROS) brings a clean corner glow to cabinets, closets, shelves and displays. Part of the 90 series, it is an 8-foot LED aluminum channel that mounts in a corner and aims the light of your strip at 45°. You may know it as an aluminum profile for LED strip lighting, an LED corner diffuser or an extruded aluminum channel; whatever the name, it turns a bare LED strip into a finished fixture for residential and commercial projects, from a single cabinet to a full retail fit-out.

Made of 6063-T5 aluminum alloy, the profile increases heat dissipation, which increases the lifetime of your LED strip. The frosted lens spreads the light for a soft finish, and the 90 series design is aimed at uniform light without hot spots. The technical drawing lists a slim 15.6 mm (0.614 in) by 17.5 mm (0.689 in) cross-section, sized for LED strips 10 mm (3/8 in) wide or less. A long lens-fitting system with an enhanced mechanical fit keeps the lens secure, the black finish stays discreet on dark cabinetry, and the series is covered by a 3-year warranty.

Picture it in a walk-in closet in Gatineau, along the corner of a home bar in Saskatoon or inside a black kitchen hutch in Moncton: the 8 ft black frosted profile adds light without adding clutter. Prefer an opaque lens? See the 8 ft black profile with opaque lens. Need a longer run? The 16 ft black profile with frosted lens uses the same design. Light your corners in style, starting today with your new LED channel.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-90, LCENDCAP-STAND-90-BK, LCENDCAP-STAND-90-H, LCENDCAP-STAND-90-H-BK

Designed for corners, dressed in black
The 90 series LED corner profile is made to be installed in a corner and offers lighting with a beam oriented at 45 degrees. That angle puts the light on what matters, the contents of a shelf, a cabinet interior or a product display, instead of pointing it straight down. In retail, the series excels at maximizing the appeal of products in POP stands while keeping a minimalist style. The LCPROF-90-8FT-BK-LENS-FROS combines a black aluminum profile with a frosted lens in a practical 8 ft length.

Soft, even light that lasts
The 6063-T5 aluminum alloy increases heat dissipation, so this aluminum extrusion increases the lifetime of your LED strip. The frosted lens softens the output of the strip, and the profile is designed to give uniform light without hot spots. The long lens-fitting system and new, enhanced mechanical fit keep the lens properly seated for long-term durability, which matters in closets and cabinets where doors open and close all day.

Installation made simple
Choose an LED strip 10 mm (3/8 in) wide or less. Measure the corner, cut the profile and lens to length with a fine-tooth saw and smooth the edges. The series spec sheet shows a 45° corner bracket and double-face mounting tape as mounting methods, and end caps with no hole, with a hole or one of each. Apply the strip in the clean channel, fit the frosted lens, then close each end with an end cap, using one with a hole where the wire exits.

Technical specifications
SKU: LCPROF-90-8FT-BK-LENS-FROS
Series: 90 (corner)
Length: 8 ft
Finish: black aluminum
Lens: frosted
Beam orientation: 45°
Cross-section (drawing): 15.6 mm (0.614 in) x 17.5 mm (0.689 in)
LED strip width: 10 mm (3/8 in) max.
Material: 6063-T5 aluminum alloy
Warranty: 3 years

Where it shines
Homeowners use a black LED profile like this one to light wardrobes, pantries, bookcases and home bars; businesses use it in boutique shelving, reception areas and product displays. In a boutique, a discreet black line of light draws the eye to the merchandise rather than to the fixture itself. It is a smart way to upgrade LED strip lighting in homes and shops across Canada. The spec sheet, with the technical drawing and ordering options, is in the Documentation tab. For a lighter décor, compare with the 8 ft profile with frosted lens.

Technical Files
