LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-BK

Name: LED ALUMINUM PROFILE #90 - LCPROF-90-8FT-BK
Brand: LEDCO
SKU: LCPROF-90-8FT-BK
Price: 55.97 CAD
Availability: InStock

SKU: LCPROF-90-8FT-BK

Brand: LEDCO

Black finishes are everywhere in modern kitchens, boutiques and bars, and this black LED aluminum profile lets your lighting follow the trend. From the 90 series, LCPROF-90-8FT-BK is an 8-foot LED aluminum channel in black aluminum, designed to mount in a corner and direct your strip light at 45°. People also look for it as an aluminum profile for LED strip lighting, a corner LED channel or an aluminum extrusion for lighting. It suits residential and commercial projects: cabinets, shelving, displays and point-of-purchase stands.

The profile is made of 6063-T5 aluminum alloy, which increases heat dissipation and helps your LED strip last longer. According to the technical drawing, its cross-section measures 15.6 mm (0.614 in) by 17.5 mm (0.689 in), and it follows an application guide for LED strips 10 mm (3/8 in) wide or less. The 90 series is designed to give a uniform light without hot spots from a corner, and the profile includes a long lens-fitting system with an enhanced mechanical fit for durability. The black finish keeps the fixture discreet against dark surfaces, and the series comes with a 3-year warranty.

From a matte-black kitchen in Laval to a craft beer bar in Edmonton, this 8 ft black corner profile adds a precise line of light without breaking your colour scheme. The same design is also listed as the 8 ft black profile with frosted lens and the 8 ft black profile with opaque lens, and longer corners can use the 16 ft black profile with opaque lens. Order your black LED channel today.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-90, LCENDCAP-STAND-90-BK, LCENDCAP-STAND-90-H, LCENDCAP-STAND-90-H-BK
Lens: LCLENS-OPAQ90-8FT-BK

A black corner profile for modern spaces
The 90 series was designed for one job: lighting from a corner. Installed where two surfaces meet, this LED corner profile offers lighting with a beam oriented at 45 degrees, so the light lands on the display, the shelf or the counter rather than straight down. It excels at maximizing the appeal of products in POP stands while keeping a minimalist style. The LCPROF-90-8FT-BK version is finished in black aluminum and comes in an 8 ft length that is easy to handle on the job.

Why aluminum matters
LED strips last longer when they stay cool. Made of 6063-T5 aluminum alloy, this aluminum extrusion increases heat dissipation, and its use increases the lifetime of your LED strip. It also turns a loose strip into a finished fixture that looks intentional. The series is designed to give uniform light without hot spots, and its long lens-fitting system with a new, enhanced mechanical fit keeps a lens securely in place over the years.

Installation
Pick an LED strip 10 mm (3/8 in) wide or narrower, as the application guide recommends. The series spec sheet shows two mounting options, a 45° corner bracket and double-face mounting tape, plus end caps with no hole, with a hole or one of each. Cut the profile to the length of your corner with a fine-tooth blade, clean it, apply the strip, then complete the assembly and close the ends. Plan the wire exit before mounting, so the power lead leaves neatly through an end cap with a hole. The 8 ft length is easy to carry into a condo or a small shop.

Technical specifications
SKU: LCPROF-90-8FT-BK
Series: 90 corner profile
Length: 8 ft
Colour: black aluminum
Light orientation: 45°
Drawing dimensions: 15.6 mm (0.614 in) and 17.5 mm (0.689 in)
Strip width: 10 mm (3/8 in) or less
Alloy: 6063-T5 aluminum
Warranty: 3 years

Projects and documentation
Use it along the top corner of black open shelving, inside a dark wardrobe, under the corner of a bar top or around a boutique display wall. Across Canada, designers choose a black LED profile when the fixture should disappear and only the light should show, in residential and commercial projects alike. The spec sheet, with the technical drawing and ordering options, is in the Documentation tab. Comparing versions? See the 8 ft black profile with frosted lens and the 8 ft black profile with opaque lens.
