3.5" LUNA LED LINEAR GIMBAL COLOR SELECTABLE RECESSED FIXTURE - RA35M-3L-9G-DTW90WH

Name: 3.5" LUNA LED LINEAR GIMBAL COLOR SELECTABLE RECESSED FIXTURE - RA35M-3L-9G-DTW90WH
Brand: LITELINE
SKU: RA35M-3L-9G-DTW90WH
Price: 267.97 CAD
Availability: InStock

SKU: RA35M-3L-9G-DTW90WH

Brand: LITELINE

Two adjustable beams, one clean slot in the ceiling: the 3.5" LUNA LED Linear Gimbal Color Selectable Recessed Fixture (SKU RA35M-3L-9G-DTW90WH) is the kind of recessed lighting that makes a room look designed instead of just lit. People call it a linear pot light, a multi-head gimbal downlight, a two-light recessed LED fixture or simply an adjustable slot light — whatever the name, it does the same job beautifully: aiming light exactly where you want it. Each of the two heads pivots on a gimbal, so you can wash a stone fireplace, graze a feature wall, light a kitchen island or point both beams straight down for even general lighting. Its white trim finish blends into a painted ceiling, and the compact 3.5" LUNA platform slips into tight joist spaces where a big round can simply will not go.

Inside the durable airtight aluminum body sits an 18W LED module delivering up to 1675 lumens and up to 101 lumens per watt, with a typical CRI of 94 so wood tones, paint colours, food and skin all look true. An on-fixture color selectable switch gives you five colour temperatures — 2700 K, 3000 K, 3500 K, 4000 K and 5000 K — meaning one fixture covers a cozy living room and a crisp commercial space. The lens produces a controlled 38° beam spread, and dimming runs smoothly from 100% down to 10% on standard forward-phase / reverse-phase and TRIAC/ELV dimmers. Input is 100-135V AC, 50/60Hz, power factor greater than 0.90, projected life 70% at 50,000 hours, cETLus certified, Energy Star, Class II, suitable for wet locations, approved for direct contact with insulation, airtight, rated from -20°C to 40°C, and backed by a lifetime warranty. Hole cut is 7¼" × 3 5⁄8" (184 × 92 mm).

This LUNA linear gimbal is right at home over kitchen counters and islands, in hallways, bedrooms, basements, finished garages, covered porches and soffits, and in boutiques, clinics, restaurants and offices. Because it is airtight, insulation-contact and wet-location rated, it handles Canadian realities: attic insulation above the ceiling, bathrooms and showers, and winter temperatures down to -20°C. Prefer a darker trim or a different head count? See the matching Luna linear gimbal in black, the brushed nickel version or the 2-light white model. Add it to your project and light exactly what deserves attention.

Built to last, built to disappear
The LUNA platform starts with a durable airtight aluminum body and an adjustable gimbal for each light head, so the fixture stays cool and stays put once aimed. An anodized blue heat sink maximizes airflow around the LED light source, which is exactly what protects lumen output and colour consistency over the long haul — the projected life is 70% at 50,000 hours, and the fixture carries a lifetime warranty. Mounting is quick: four spring-loaded clips grip any ceiling material, making this a friendly retrofit recessed fixture for renovations where you are cutting into existing drywall. The hole cut is 7¼" × 3 5⁄8" (184 × 92 mm).

Light quality and colour selection
The 18W LED module maintains uniform intensity and produces up to 1675 lumens with a typical CRI of 94 — a level of colour rendering you usually reserve for retail displays, galleries and kitchens where food prep matters. The on-fixture color selectable switch offers five colour temperatures with published outputs: 1490 lumens at 2700 K, 1544 lumens at 3000 K, 1666 lumens at 3500 K, 1676 lumens at 4000 K and 1638 lumens at 5000 K. The lens delivers a 38° beam spread, tight enough to accent artwork or a backsplash, wide enough to share general recessed downlighting duty when both heads face down.

Electrical and installation details
Power comes from an extruded aluminum hardwire box housing two 210mA dimmable Class II electronic LED drivers with 100-135V AC input. An 18" FT6 rated cable with a DC 2.1 connector links the driver to the fixture and is approved for use in plenums and suspended ceilings. "Quick connect" push-in terminals speed up wiring on site. Dimming runs from 100% to 10% with industry standard forward-phase / reverse-phase and TRIAC/ELV dimmers (contact factory for the list of compatible dimmers). The fixture is suitable for wet locations, approved for direct contact with insulation, airtight, and operates from -20°C to 40°C (-4°F to 104°F).

Technical specifications
SKU: RA35M-3L-9G-DTW90WH
Application: Ceiling Recess Mount
Approved location: Wet / Insulated Ceilings
Wattage: 18W
Lumens: Up to 1675
Lumens per watt: Up to 101
CCT (color selectable): 2700 K / 3000 K / 3500 K / 4000 K / 5000 K
CRI: 94
Beam angle: 38°
Input: 100-135V AC, 50/60Hz
Power factor: >0.90
Dimming: Yes, forward/reverse-phase TRIAC/ELV
Hole cut: 7¼" × 3 5⁄8" (184 × 92 mm)
Certification: cETLus, Energy Star, Class II
Projected life: 70% @ 50,000 hrs
Warranty: Lifetime

Applications, options and documentation
Think kitchen islands and perimeter counters, hallways that need a rhythm of light, a reading nook over a bed, a basement bar, a covered entry or soffit, and commercial jobs like a boutique fitting area, a dental operatory, a café banquette or a reception desk. Accessories are sold separately, including a premounting plate for the LUNA 2-light linear gimbal (P-3520-2L) and a new construction mounting kit (P-NCMK-1) with hanger bars, brackets and screws for framing stage installs, plus the VBE-1 vapour barrier extender — a must when searching for a recessed lighting vapor barrier solution in Canadian ceilings. Within the same family you can mix finishes and head counts: white 3-light, black 2-light or brushed nickel 2-light. The full technical PDF spec sheet is available in the Documentation tab for your submittals and permit packages.
