LL SERIES FOR LIGHT RESIDENTIAL APPLICATIONS - TK6004-SL

Name: LL SERIES FOR LIGHT RESIDENTIAL APPLICATIONS - TK6004-SL
Brand: LITELINE
SKU: TK6004-SL
Price: 43.97 CAD
Availability: InStock

SKU: TK6004-SL

Brand: LITELINE

Give your kitchen island, hallway or shop display the kind of light that actually lands where you want it. The LL Series track rail TK6004-SL from LITELINE is a 4-ft single-circuit track lighting rail in a silver finish — the classic 4ft track lighting bar people look for when they want to aim several heads along one clean line. Call it a track rail, a lighting rail or simply the bar that your track light heads clip into: it's the backbone of the whole system, and everything else (heads, connectors, feeds, end caps) builds off it.

This is extruded aluminum track with flat, solid integral conductors rated 20 amps per branch circuit. The system electrical rating is 20A, 120V, 60Hz, so it drops right into standard residential and light commercial circuits. Construction is 1⁄32" die-cast aluminum with 3⁄64" PVC insulators holding 12-gauge flat conductor wiring, and a polarity groove runs along the face of the track to show exactly where the grounding conductor sits — no guesswork when you slot in a head. The copper electrical conductors stay concealed inside an insulating thermoplastic cross-section, and the low-profile extrusion measures just ¾" (21 mm) by 1 3⁄8" (35 mm) with a 48" (1219 mm) length. The silver (SL) finish keeps it discreet against white, grey or wood ceilings.

Track rails like this one earn their keep in open-plan condos, basement renos, kitchens, home offices, art walls, boutiques, cafés, salons and small galleries — anywhere a Canadian homeowner or contractor needs to relight a room without cutting a dozen holes in the ceiling. Sections join end to end with any compatible Liteline track connector, so a long run or an L-shaped layout is simply a matter of adding pieces. Need a different look? The same 4-ft rail is offered as LL Series track TK6004-BK in black, TK6004-BN in brushed nickel and TK6004-WH in white. Start your run with the TK6004-SL and build the lighting layout your room has been missing.

Built from solid extruded aluminum
The TK6004-SL is a 4-ft section of LITELINE LL Series track, made from 1⁄32" die-cast aluminum extrusion. Inside, 3⁄64" PVC insulators hold 12-gauge flat conductor wiring in place, and the copper electrical conductors are fully concealed in an insulating thermoplastic low-profile rack cross-section. A polarity groove is located on the face of the track to indicate the location of the grounding conductor, which makes orienting heads and connectors quick and repeatable. At ¾" (21 mm) high and 1 3⁄8" (35 mm) wide, the profile stays visually light on the ceiling while the extrusion does the structural work.

Single-circuit 120V power, 20 amps
This is a 1-circuit track designed for 120V applications. The single hot and neutral conductors are rated for 20 Amps per branch circuit, and the system electrical rating is 20A, 120V, 60Hz. Track lighting is a single-circuit electrical distribution system built to supply power to lighting units in flexible ways — meaning you decide where the light goes, and you can change your mind later without touching the drywall. One feed, one circuit, as many heads as your load calculation allows.

Technical specifications
SKU: TK6004-SL
Brand: LITELINE
Series: LL Series / TK60 track sections
Length: 48" (1219 mm)
Profile: ¾" (21 mm) x 1 3⁄8" (35 mm)
Finish: SL — Silver
Construction: 1⁄32" die-cast aluminum extrusion, 3⁄64" PVC insulators, 12-gauge flat conductor wiring
Circuits: 1-circuit
System electrical rating: 20A, 120V, 60Hz

Connectors, feeds and accessories
The Liteline track system is compatible with all Liteline track accessories and connectors, and sections join together using any of the compatible track connectors. Power can come in several ways: CA6106 live-end conduit feed (7⁄8" knockout) for top or end feed, CF6108 center feed with canopy cover for power anywhere along the track from a junction box, LE6110 live-end (no canopy), LE6111 live-end with canopy, or WE6110 wired-end that feeds the track from a receptacle. To shape the run, use the IC6101 I-connector at 180°, the LC6102 L-connector at 90°, the TC6103 T-connector for three sections at 90°, the XC6104 X-connector for four sections at 90°, or the FC6105 flexible connector for varying angles. Finish the run with a TK6000-END end cap. For suspended installations, the TDR62 hollow stem rod kit includes the ceiling canopy, mounting brackets and hardware, while RODR62 suspends the track from the ceiling and RODF62 drops the fixtures themselves. Accessories are sold separately.

Where it works and what's in the box of documents
Use this 4-ft rail over a kitchen island or peninsula, along a hallway of framed photos, above a home office desk, in a finished basement, or across a retail display wall, café counter, salon station or small gallery. Two or three sections joined with connectors cover a long living room; an L-connector turns a corner into a continuous run. Because the whole layout is modular, the same track can serve a boutique that rearranges its displays every season. The full TK6004-SL spec sheet is available in the Documentation tab of this page with the technical drawings, ordering guide and accessory list. Prefer another finish for the same rail? See TK6004-BK in black or TK6004-WH in white, and if you'd rather start with a ready-made set, the track kit TK6004-WH-KIT2 and track kit TK6004-BK-KIT2 are built around the same 4-ft rail.
