SET OF 50 DOUBLE 2835 LED MODULES ( 0.5W PER MODULE )

Name: SET OF 50 DOUBLE 2835 LED MODULES ( 0.5W PER MODULE )
Brand: LED MONTREAL
SKU: 2835MOD2
Price: 44.97 CAD
Availability: InStock

SKU: 2835MOD2

Brand: LED MONTREAL

Need bright, flexible light where a regular strip just won't bend? Meet the Set of 50 Double 2835 LED Modules from LED MONTREAL (SKU 2835MOD2), a chain of 50 small injection-moulded modules wired on a single string, each one holding two SMD2835 LEDs. People look for these as LED modules, LED module chains, sign modules, backlight modules, module strips or simply as an alternative to LED light strips when the run has to turn corners, follow a curve or hide inside a channel letter. Because each module sits on its own flexible lead, you place light exactly where you want it instead of fighting a rigid tape: channel letters and lightboxes, sign cabinets, cove and soffit backlighting, display cases, shelving, toe-kicks, bar fronts and reception desks.

Every module runs on 12V DC constant voltage and draws 0.48W (0.5W per module) at 80 mA, delivering 46 lm each with a wide 160° beam angle that spreads light evenly instead of leaving hot spots — ideal behind acrylic faces. The colour temperature is a crisp, punchy 6000-7000K cool white that reads clean and bright from the street. Each module measures 44 x 14.6 x 7 mm with 65 mm centre-to-centre spacing between modules, so a full string covers a generous run, and you can chain a maximum of 50 pieces in one row. The IP67 rating means the modules are sealed against dust and water, and they operate from -20 to 45 °C — a real consideration for anything mounted outdoors or in an unheated space.

These modules are a favourite of sign shops, cabinet makers, contractors and DIY renovators across Canada: storefront signage, lit lettering, menu boards, glass display cabinets in a boutique, under-counter lighting in a kitchen, stair nosings, or accent lighting in a basement bar. Pair the string with any 12V DC constant-voltage LED driver sized for your total load, respect the 50-module maximum per row, and run additional strings in parallel back to the power supply for longer installations. Peel, stick or screw each module down, tuck the leads out of sight, and you get a clean, even glow no rigid product can match. Order your set of 50 double 2835 LED modules and light up your next project the easy way.

Construction and design
Each unit in this string is a compact, resin-sealed module measuring 44 x 14.6 x 7 mm and carrying two SMD2835 LEDs. The modules are joined by flexible wire leads with a 65 mm centre-to-centre distance, which is what makes this product so different from a standard LED strip light: the light points stay separate, so you can spread them across a wide surface, wrap them around a radius or drop them into narrow letter returns. The low 7 mm profile lets the modules disappear inside shallow cabinets, channel letters and aluminum extrusions, and the sealed body protects the diodes and solder joints from moisture and dust.

Light output and colour
Each double module produces 46 lm with a 160° beam angle. That very wide spread is the key to even backlighting — placed behind an acrylic or polycarbonate face, the beams overlap and eliminate the striping and hot spots you get from narrow-beam sources. The 6000-7000K colour temperature is a bright cool white with a clean, high-visibility look that stands out on signage, in display cases and in task areas. With 50 modules in the set, you can cover a long letter, a wide lightbox or several smaller elements from one string.

Technical specifications
SKU: 2835MOD2
Brand: LED MONTREAL
LED type: SMD2835
Quantity per module: 2
Power: 0.48W per module (0.5W per module)
Working voltage: 12V DC
Working current: 80 mA per module
Luminous flux: 46 lm per module
Beam angle: 160°
Driving mode: constant voltage
Dimensions: 44 x 14.6 x 7 mm
Colour temperature: 6000-7000K
Module centre distance: 65 mm
Modules per set: 50
Max. number of modules in one row: 50 pcs
IP rating: IP67
Working temperature: -20 to 45 °C

Electrical and installation notes
This is a constant-voltage 12V DC product, so it needs a 12V DC power supply rated for your total load — add up 0.48W per module and choose a driver with headroom. Never exceed 50 modules in a single row; for bigger jobs, run several strings in parallel back to the supply rather than extending one line, which keeps the brightness uniform from the first module to the last. Mount the modules with their adhesive backing on a clean, dry surface, or fasten them mechanically inside metal letters and cabinets. Keep polarity consistent, seal any field connections, and leave a little slack in the leads so nothing pulls at a joint. The IP67 construction and the -20 to 45 °C operating range make the modules suitable for damp and cold locations, though the driver and connections must always be housed in an enclosure rated for their environment.

Applications and documentation
Sign shops use these 2835 LED modules to backlight channel letters, lightboxes and menu boards; retailers light glass showcases, shelving and window displays; homeowners and contractors hide them under kitchen cabinets, in coves, along stair nosings and behind bar fronts where a rigid strip cannot follow the shape. They also work well in restaurant and salon signage, garage workbenches and basement renovations. No spec sheet, IES file or installation video is posted in the Documentation tab for this item; the full technical parameters above are taken directly from the manufacturer's data, and our team is happy to help you size the driver and plan the layout for your project.
