120V AC UNIVERSAL WALL DIMMER FOR LED LIGHTS AND LED DRIVERS

Name: 120V AC UNIVERSAL WALL DIMMER FOR LED LIGHTS AND LED DRIVERS
Brand: LED MONTREAL
SKU: UNIDIM
Price: 27.97 CAD
Availability: InStock

SKU: UNIDIM

Brand: LED MONTREAL

Finally, a wall dimmer that actually plays nice with LED. The 120V AC universal wall dimmer from LED Montreal (SKU UNIDIM) is the slide-style dimmer switch built specifically for LED products — LED bulbs, LED drivers and the fixtures they feed. If you have been searching for an LED-friendly wall dimmer, a replacement for an old low-voltage magnetic dimmer, or a standard dimmer that finally stops your lights from flickering, buzzing or dropping out at the bottom of the range, this is the one to put in the box.

It runs on 120V AC and supports up to 300W of LED bulbs or universal dimmable drivers, which covers most residential rooms and plenty of small commercial jobs on a single device. It replaces both low-voltage magnetic dimmers and standard dimmers, and it is fully compatible with the 24V Universal Dimmable LED Driver and the 12V Universal Dimmable LED Driver, as well as 120V LED bulbs. The secret is the adjustable low-end trim thumbwheel: you set the minimum dim level yourself, so your lights fade down smoothly instead of cutting out or shimmering. The fluid slide bar gives you precise, gradual control of a single-colour LED strip or any LED fixture, and the separate ON/OFF switch lets you kill the lights and bring them back exactly where you left them — no need to re-set your favourite level every evening.

Put it in a living room, a bedroom, a kitchen, a home theatre, a basement reno, or in a restaurant, boutique, clinic or office where the mood has to change through the day. It is designed for residential and commercial projects, which makes it a natural pick for Canadian homeowners upgrading old incandescent dimmers, contractors wiring a whole floor of pot lights, and small business owners who want one clean control on the wall. Pair it with your LED drivers and single-colour LED strip runs, set the low end once, and enjoy dimming that finally behaves. Add the UNIDIM to your next order and give your LED lighting the control it deserves.

Built for LED, not adapted to it
Most dimming headaches come from using a control designed for incandescent loads on modern LED electronics. The UNIDIM takes the opposite approach: it is an AC slide wall dimmer engineered around LED bulbs and LED drivers from the start. It replaces both low-voltage magnetic dimmers and standard dimmers, so one device can cover a mixed renovation where some circuits feed 120V LED bulbs and others feed low-voltage LED strip through a driver. The slide bar moves fluidly through the range, giving you fine, gradual control rather than the coarse jumps you get from a cheap rotary control.

The low-end trim makes the difference
The feature that sets this dimmer apart is the adjustable low-end dim setting thumbwheel. Every LED load has its own minimum stable point; below that point, lights flicker, shimmer or drop out entirely. With the thumbwheel you dial that floor in yourself, once, at commissioning: slide the control to its lowest position, then turn the wheel until the light sits steady and low. From then on, the full travel of the slider is usable and the fade to the bottom stays smooth. This is exactly what makes the UNIDIM so widely compatible across LED bulbs, drivers and strip installations.

Technical specifications
SKU: UNIDIM
Brand: LED Montreal
Type: AC slide wall dimmer
Input voltage: 120V AC
Maximum load: 300W of LED bulbs or universal dimmable drivers
Controls: fluid slide bar, ON/OFF switch, adjustable low-end dim setting thumbwheel
Compatibility: 24V Universal Dimmable LED Driver, 12V Universal Dimmable LED Driver, 120V LED bulbs, single-colour LED strip and LED lights
Applications: residential and commercial

Installation and compatibility
The UNIDIM mounts in a standard wall box on the line side of your lighting circuit, controlling 120V AC before it reaches your bulbs or your driver. For a single-colour LED strip, wire the dimmer ahead of a 24V or 12V Universal Dimmable LED Driver and let the driver translate the signal to the tape — you keep the control on the wall where people expect it, with no extra remote or inline module. For 120V LED bulbs, it wires like any conventional dimmer. Keep the total connected load within the 300W maximum, and remember that the ON/OFF switch is there so users can cut the lights without touching the slider, preserving the level you set. Wiring should be done by a qualified electrician in accordance with the Canadian Electrical Code and your local requirements.

Where it earns its keep
In a home, it is the control you want on a dining room chandelier, a kitchen island run of LED tape, a basement home theatre or a bedroom cove. In commercial work, think restaurant dining rooms that shift from bright lunch service to low evening ambiance, boutiques highlighting displays, waiting rooms, salons, clinics and small offices. For contractors, the value is simple: one universal wall dimmer to stock instead of guessing between magnetic low-voltage and standard models on every call-back. Pick up the UNIDIM with your LED drivers and strip and you have a complete, dimmable system from the wall plate to the last LED.
