10 FEET INTERIOR ALUMINUM U SHAPE PROFILE FOR LED STRIP (LUX745)

Name: 10 FEET INTERIOR ALUMINUM U SHAPE PROFILE FOR LED STRIP (LUX745)
Brand: LED MONTREAL
SKU: 10FLUX745
Price: 69.97 CAD
Availability: InStock

SKU: 10FLUX745

Brand: LED MONTREAL

Give your LED strip the clean, finished look it deserves with the 10 FEET INTERIOR ALUMINUM U SHAPE PROFILE FOR LED STRIP (LUX745) from LED Montreal. Also called an aluminum extrusion, LED channel, U-channel or track for led strip lights, this long extruded aluminum profile turns a bare strip of tape light into a real architectural light line. It hides the copper pads, the solder points and the adhesive backing, protects the strip from bumps and dust, and spreads the light more evenly so you see a glow instead of a row of dots. Homeowners use it under cabinets, along staircases and in coves; contractors use it for ceiling light lines, display cases and signage. One long 10-foot length also means fewer joints and fewer visible seams on a long run.

This is the U shape (surface) model, SKU 10FLUX745, measuring 10 feet (3.05 m) long, 26.2 mm wide and 11.5 mm high. The generous channel opening accepts LED strips of less than 14 mm in width, including IP20, IP65+ and IP67 strips, which gives you real freedom when you choose your tape. Strips wider than 14 mm, such as certain IP67 and IP68 types, will not fit, so measure before you order. Aluminum is also a natural heat sink: mounting your strip inside the channel helps pull heat away from the LEDs, which is the single best thing you can do for the longevity and colour stability of an led strip lighting installation.

Because of its length, this profile is available at our service counter only — it cannot be shipped by mail. It works beautifully in kitchens, basements, home theatres, offices, boutiques, restaurants and workshops across Canada, wherever you want a continuous, professional light line. Finish the job with matching end caps for a truly polished result. Need a shorter run for a smaller project? The 8 feet recessed aluminum U shape profile for LED strip (LUX745) uses the same profile family. Drop by the counter, bring your measurements, and let's build your light line.

Built from extruded aluminum
The LUX745 is a full extruded aluminum channel, not a plastic imitation. The U shape (surface) design gives you a deep, open channel with two side walls that shield the LED strip from side glare and physical contact, while the flat base gives the tape a perfectly straight, rigid surface to adhere to. On a 10-foot run, that rigidity matters: an unsupported strip stuck directly to drywall or wood will sag, wander and show every wave, while a strip seated in an aluminum extrusion stays dead straight from end to end. The aluminum body also acts as a heat sink, drawing heat away from the LED chips so the diodes run cooler and hold their colour over time.

Technical specifications
Model: 10FLUX745
Type: U Shape (Surface)
Length: 10 Feet (3.05 m)
Width: 26.2 mm
Height: 11.5 mm
Strip compatibility: LED strips of less than 14 mm in width
Brand: LED Montreal

Choosing the right LED strip
This channel was designed for led strip lights measuring less than 14 mm wide, which covers most standard IP20 indoor tapes as well as IP65+ and IP67 silicone-coated strips. It is not suitable for wider tapes, including certain IP67 and IP68 formats that exceed 14 mm — always check the width printed on your strip's spec sheet before cutting anything. If you are planning a long continuous run, remember to respect your strip's maximum run length and to feed power from both ends when the manufacturer calls for it, so the far end of your led strip lighting stays as bright as the first metre.

Installation, mounting and finishing
Mount the channel first, then install the strip. Lay the profile along your surface, mark your fixing points, and anchor it with screws suited to the substrate — wood, drywall with anchors, or metal. Cut the aluminum to length with a fine-tooth blade or mitre saw and deburr the edges, then run the strip inside, keeping the adhesive fully pressed down along the base. Plan your power entry point and your driver location before you close everything up, and leave the low-voltage wire accessible. Adding matching end caps at each extremity hides the cut edges, keeps dust out and gives the whole installation that clean, custom look. On a ceiling light strip or cove run, mounting the channel at a slight angle lets you aim the light exactly where you want it.

Applications, availability and documentation
Typical uses include under-cabinet and over-cabinet kitchen lighting, island and bar accents, staircase and hallway guidance, closet and pantry lighting, toe-kick details, home theatre coves, garage and workshop task lines, plus retail shelving, display cases, reception desks and backlit signage for small businesses. Because of its 10-foot length, this profile is available at our service counter only and cannot be sent by mail — plan a pickup with your vehicle ready for a long load. For a shorter run or a tighter space, look at the 8 feet recessed aluminum U shape profile for LED strip (LUX745). The full technical PDF for model 10FLUX745, with the profile type and dimensions, is available in the Documentation tab of this page.
