LED ALUMINUM PROFILE #94 - LCPROF-94-16FT-BK

Name: LED ALUMINUM PROFILE #94 - LCPROF-94-16FT-BK
Brand: LEDCO
SKU: LCPROF-94-16FT-BK
Price: 586.97 CAD
Availability: InStock

SKU: LCPROF-94-16FT-BK

Brand: LEDCO

Make a bold architectural statement with the black LED aluminum profile #94 (LCPROF-94-16FT-BK). This 16-foot aluminum extrusion in black has a 41.3 mm (1.630 in) square cross-section and twin mounting channels, ready to be surface mounted, fitted on swivel arms or suspended as a sleek line of light. Also searched as a black LED aluminum channel, an aluminum profile for LED strip lighting or an extruded aluminum light fixture body, it suits restaurants, lofts, boutiques and modern offices.

The profile is built in rugged 6063-T5 aluminum alloy that withstands abuse in demanding applications and extreme weather, and the alloy increases heat dissipation for an extended lifetime of the LED source. A 33 mm (1.25 in) wide area accepts multiple or oversized LED sources for extra power, with application guides for 10 mm (3/8 in) LED strips, and 3 position slots for the heat-sink insert let you set the needed beam angle. The design delivers uniform light without hot spots, the black finish disappears against dark ceilings and façades, and the profile is covered by a 3-year warranty.

Picture a suspended black line over the bar of a Québec City bistro, a row of sign lights on a dark storefront in Hamilton or an exposed-ceiling office in Vancouver: the #94 in black ties it all together, whether you need black linear lighting indoors or sign lighting outside. Prefer another colour? See the aluminum 16 ft profile #94 or the white 16 ft profile #94. For shorter runs, the black 8 ft profile #94 uses the same design. Order your black LED profile today.

Black, sturdy and versatile
The 94 series is a sturdy aluminum profile with an understated elegance, and in black it becomes a design element in its own right. Its twin mounting channels allow a wide range of installation options, on swivel arms, on a surface or suspended, and with corner joiners it can be built into complex spatial configurations such as a rectangle over a boardroom table. The LCPROF-94-16FT-BK is the black version (94BK on the ordering guide) in a 16 ft length, a natural choice for a black suspended LED light or a black linear fixture.

Performance inside the profile
Made of 6063-T5 aluminum alloy, the profile increases heat dissipation for an extended lifetime of the LED source, and the alloy is suitable for outdoor installation. Its 33 mm (1.25 in) wide LED area accepts multiple or oversized LED sources for extra power, and application guides help align 10 mm (3/8 in) wide LED strips. Three position slots for the LED heat-sink insert set the beam angle your project needs, while the design gives uniform light without hot spots.

Mounting in black
Its mounting channels make the #94 compatible with a wide range of installation accessories. The spec sheet lists clip-in brackets, surface brackets (1-side, 2-side and 90°), swivel wall brackets, swivel sign arms with 6 in or 18 in offset and a suspension kit with 15 ft aircraft cable, most of them offered in black as well, along with canopies for a remote or integrated driver. Corner joiners at 90° (including a black version) and 135°, and a straight joiner, are ordered separately. Lens options on the sheet include clear, opal and focus lenses.

Technical specifications
SKU: LCPROF-94-16FT-BK
Series: 94
Colour: black (94BK)
Length: 16 ft
Cross-section (drawing): 41.3 x 41.3 mm (1.630 x 1.630 in)
LED area: 33 mm (1.25 in) wide
Application guides: 10 mm (3/8 in) LED strips
Beam setting: 3 position slots for the heat-sink insert
Material: 6063-T5 aluminum alloy, suitable for outdoor installation
Warranty: 3 years

Ideas for the black #94
Suspend it over restaurant tables, a hotel reception desk or a retail cash area; mount it on black swivel sign arms above a storefront; or run it along a dark wood ceiling in a modern home. Designers across Canada use a black aluminum profile like this one to blend the fixture into the architecture and let the light do the talking, in commercial and residential projects. The spec sheet with the full ordering guide is in the Documentation tab. Want a matching shorter piece? See the black 8 ft profile #94.
