LED ALUMINUM PROFILE #49 - LCPROF-49-16FT-WH-LENS-OPAQ

Name: LED ALUMINUM PROFILE #49 - LCPROF-49-16FT-WH-LENS-OPAQ
Brand: LEDCO
SKU: LCPROF-49-16FT-WH-LENS-OPAQ
Price: 339.97 CAD
Availability: InStock

SKU: LCPROF-49-16FT-WH-LENS-OPAQ

Brand: LEDCO

Looking for an LED aluminum profile that delivers a soft, seamless line of light on a white ceiling? This version of the large square #49 series, model LCPROF-49-16FT-WH-LENS-OPAQ, pairs the white profile with an opaque lens, so the LED strip inside disappears behind a smooth, uniform surface. Often searched as an LED aluminum channel, an aluminum extrusion or an aluminum profile for LED strip lighting, it turns an ordinary strip into a clean linear fixture for kitchens, offices, clinics, boutiques and restaurants, in a 16-foot length that covers long runs.

The profile measures 43 × 43 mm (1.693 in), a large square shape with a confident architectural line. Its channel, 39 mm wide and 20.32 mm deep, accommodates a wide range of LED strips, and the aluminum body provides excellent heat dissipation so your LEDs run cooler. Made of 6063-T5 aluminum in a white finish that blends with bright ceilings and walls, it can also be painted to match your decor. The opaque lens covers the strip for an even glow without visible dots. The profile is certified for the Canadian market and backed by a 3-year warranty.

Hang it as a white linear pendant over a kitchen island or a reception desk, mount it across the ceiling of a dental clinic, a salon or an open-concept office, or run it along a wall for gentle accent lighting in a condo or a finished basement. It is designed for surface or suspended mounting, suspension kits are available, and custom fabrication can adapt it to special projects. From Winnipeg to Sherbrooke, Canadian designers love this clean white look for spaces that need to feel bright, calm and uncluttered. Add your favourite LED strip and enjoy a polished result from end to end.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-49, LCENDCAP-STAND-49-BK, LCENDCAP-STAND-49-WH

White profile and opaque lens together
This model combines the white #49 aluminum profile with an opaque lens, giving the LED strip you choose a closed, neatly finished housing. The #49 series is a large square LED profile measuring 43 × 43 mm (1.693 in), designed for surface or suspended mounting. In this 16-foot length, model LCPROF-49-16FT-WH-LENS-OPAQ, it creates long, continuous lines of light with fewer joints, and its white finish lets the fixture blend quietly into a bright ceiling or wall.

Soft, uniform light
A bare LED strip shows every diode as a bright point. Behind the opaque lens, those points blend into a smooth, uniform glow that is more comfortable to look at and far more elegant, especially in a suspended linear light hanging at eye level. Inside, the channel is 39 mm wide and 20.32 mm deep, which accommodates a wide range of LED strips, and the aluminum body provides excellent heat dissipation, drawing heat away from the strip to help it perform reliably over time.

Installation
The profile is designed for surface mounting or suspended mounting, and suspension kits are available when you want a true linear pendant. The ordering guide on the spec sheet also lists double-sided mounting tape and no-hole end caps, and custom fabrication is available, including custom lengths in inches. The 6063-T5 aluminum can be painted to match your decor. Plan the layout and the power supply location before you start, and have any new wiring done by a licensed electrician according to the electrical code in force in your province.

Technical specifications
Model: LCPROF-49-16FT-WH-LENS-OPAQ
Series: aluminum profile #49, large square profile
Profile dimensions: 43 × 43 mm (1.693 in)
Channel: 39 mm wide, 20.32 mm deep
Length: 16 ft
Material: 6063-T5 aluminum
Finish: white
Lens: opaque
Mounting: surface or suspended
Certification: certified for the Canadian market
Warranty: 3 years

Where it shines
Think of a white linear pendant above a dining table, a continuous line of light in a medical or dental clinic, a bright hallway in an office, or accent lighting in a spa or a hair salon. For other areas of the same project, the family also includes the LED aluminum profile #14 in white and the LED aluminum profile #145. The complete spec sheet, with the technical drawing and ordering guide, is in the Documentation tab.
