INDOOR, 24V DC, COB LED TAPE, 5M (16.4'), 3W/FT (10W/M), 480 LEDS/M, CRI 90, DIMMABLE, 27K

Name: INDOOR, 24V DC, COB LED TAPE, 5M (16.4'), 3W/FT (10W/M), 480 LEDS/M, CRI 90, DIMMABLE, 27K
Brand: LUMENSTARLED
SKU: LS-FLI-9B-24-480-27K
Price: 147.97 CAD
Availability: InStock

SKU: LS-FLI-9B-24-480-27K

Brand: LUMENSTARLED

Say goodbye to the dotted, spotty light lines of old strip lighting. The LumenstarLED LS-FLI-9B-24-480-27K is a COB LED tape light — also called LED strip lights, LED tape strip lights or a LED ribbon — built with Chip-on-Board technology that lays hundreds of tiny chips in one continuous row. The result is a smooth, seamless band of light with no visible dots and no shadows, the kind of finish designers and cabinet makers ask for under cabinets, in coves, inside millwork, along display shelving and behind floating vanities. If you have been searching for dimmable LED strip lights or clean indoor LED lighting that looks custom instead of DIY, this is the tape that does it.

Every metre packs 480 LEDs/M (146 LEDs/ft) for that dot-free look, drawing 3W/ft (10W/M) and delivering 335 lumens per foot (1100 lumens per metre) at a warm, welcoming 2700K. Colour fidelity is excellent with a CRI >90, so wood grain, food, fabric and skin tones all read true. It runs on 24V DC, which holds brightness steadier over longer runs than 12V, and it is fully dimmable with compatible low-voltage dimming power supplies. The 120° beam angle spreads light evenly inside an aluminum channel, the roll comes in 16.4' (5M) lengths, the tape measures 5/8" (16mm) wide by 1/16" (2mm) thick and cuts every 5/8" (16mm). Each roll has a 24" (60cm) wire lead on both ends, double-sided 3M adhesive on the back, an IP22 rating for indoor use, an operating range of -25~+60°C (-13~140°F), a rated life of +65,000 hours, cULus listing and a 5-year warranty.

Use it under kitchen cabinets, in a bedroom cove, along a staircase, inside a closet, behind a bar, in retail display cases, restaurants, salons and offices — anywhere a soft, even line of light makes the room feel finished. For a professional result, mount it in an aluminum profile such as the LL10 Standard 1M frosted channel, the LL12 Standard 2M frosted channel, the LL13 Standard 1M frosted channel or, for curves and arches, the LL14 Standard 2M flexible channel. Plan your run, add a 24V driver, and light it up.

Built for light lines you can actually stare at
The Single Color 10W COBFlex LED Strip uses chip-on-board (COB) technology: instead of spaced-out individual emitters, hundreds of chips are bonded directly to the board and covered by a continuous phosphor layer. At 480 LEDs/M (146 LEDs/ft), the output reads as one uninterrupted line with no dotting and no scalloping on adjacent surfaces — a big deal when the tape sits at eye level under an upper cabinet, in a glass display case or in an open cove. The flexible substrate is only 1/16" (2mm) thick and 5/8" (16mm) wide, so it tucks into slim profiles and tight millwork reveals, and the factory-applied double-sided 3M tape on the back makes mounting fast and clean.

Light quality that flatters everything
With a CRI greater than 90 and a warm 2700K colour temperature, this COB LED tape gives the relaxed, incandescent-like glow homeowners love while still rendering colours accurately. Retail displays, bakery cases, art walls, kitchens and hospitality spaces all benefit: reds stay rich, whites stay clean, wood and stone look like themselves. The 120° beam angle fills an aluminum channel evenly, and with a frosted lens the diffusion is complete — you see the light, not the source.

Technical specifications
SKU: LS-FLI-9B-24-480-27K
Brand: LumenstarLED
Voltage: 24V DC
Wattage: 3W/ft (10W/M)
Lumen output: 335/ft (1100/M)
Colour temperature: 2700K
CRI: >90
LED density: 146 LEDs/ft (480 LEDs/M)
Beam angle: 120°
Cut increment: 5/8" (16mm)
Roll length: 16.4' (5M)
Dimensions: 5/8" (16mm) wide x 1/16" (2mm) thick
Dimmable: Yes
IP rating: IP22
Operating temperature: -25~+60°C (-13~140°F)
Lifespan: +65,000 hours
Lead wire: 24" (60cm) on both ends
Listing: cULus
Warranty: 5-year

Wiring, dimming and installation
This is a low-voltage 24V DC LED tape, so it needs a 24V constant-voltage driver sized to your run: multiply 10W per metre by your total length and leave headroom. For dimming, pair it with a compatible low-voltage dimming power supply — the tape itself is fully dimmable, and the control happens at the driver. Cut only on the marked 5/8" (16mm) increments, then rejoin or feed sections with the COB solderless connectors: LS-SC1-COB seamless strip-to-strip, LS-SC2-COB with a 24" wire lead, LS-SC2-COB-20 with a 20' (6.1m) lead, LS-SC3-COB with leads on both ends, LS-SC4-COB for corners, or the compact LS-BK-SC2-COB wire-to-strip connector. The 24" (60cm) leads already on both ends of the roll often save you a connector at the feed point. With IP22 protection, keep it to dry indoor locations.

Channels, applications and documentation
The strip is optimized for installation in aluminum channel, which protects it, diffuses the light and sinks heat. Straight runs suit the LL10 Standard 2M frosted channel for slim recessed work, the LL12 Standard 1M frosted channel for a slim modern surface look, and the LL13 Standard 2M frosted channel when you want a wider, softer band; curved coves, arches and rounded islands call for the LL14 Standard 1M flexible channel. Typical projects across Canada: under-cabinet task lighting in a kitchen reno, cove lighting in a condo living room, shelf and display lighting in a boutique, reception desk accents in an office, closet and pantry lighting, and backlit bathroom mirrors. The full technical PDF (LS-FLI-9B-24-480-27K spec sheet) is in the Documentation tab with the complete specification table, dimensions, ordering codes and accessory list.
