INDOOR, 12V DC, COB LED TAPE, 5M (16.4'), 3W/FT (10W/M), 480 LEDS/M, CRI 90, DIMMABLE, 4K

Name: INDOOR, 12V DC, COB LED TAPE, 5M (16.4'), 3W/FT (10W/M), 480 LEDS/M, CRI 90, DIMMABLE, 4K
Brand: LUMENSTARLED
SKU: LS-FLI-9B-12-480-4K
Price: 147.97 CAD
Availability: InStock

SKU: LS-FLI-9B-12-480-4K

Brand: LUMENSTARLED

Say goodbye to visible dots: the LUMENSTARLED LS-FLI-9B-12-480-4K is a 12V COB LED tape light that creates one continuous, perfectly smooth line of light. Part of the Single Color 10W COBFlex family, this COB LED strip, also called a dotless LED strip, LED light strip, LED ribbon or flexible LED tape, is made for indoor LED lighting: under-cabinet and cabinet lighting, coves, display cases, millwork, shelving and accent lighting where the light line itself may be visible. It comes on a 16.4' (5M) roll, ready for residential and commercial projects.

The spec sheet gives the details for the 12V version: 3W/ft (10W/M), a lumen output of 335/ft (1100/M), 480 LEDs per metre, a 120° beam and a CRI above 90 for rich, natural colours. The 4000K neutral white sits between warm comfort and cool clarity, ideal for kitchens, bathrooms, offices and retail displays. This dimmable LED strip can be cut every 1" (25mm), has a 24" (60cm) wire lead on both ends, an IP22 rating, a lifespan of +65,000 hours, is c UL us certified and comes with a 5-year warranty.

Chip-on-board technology gives the kind of seamless glow designers love in modern Canadian kitchens, condos, boutiques, restaurants and galleries. For best results, install it in an aluminium channel such as the LL12 standard frosted channel, and power it with a compatible 12V low-voltage dimming power supply. Order the LS-FLI-9B-12-480-4K and enjoy clean, dot-free light lines.

COB technology for dot-free light
Traditional LED tape places individual LEDs at intervals, which can create visible hot spots. This COB LED tape uses chip-on-board technology with a density of 146 LEDs/ft (480LEDs/M), producing continuous, dot-free output and high visual comfort. It is optimized for installation in aluminium channels, where it delivers clean light lines worthy of architectural, display, millwork and accent lighting projects.

Light quality and colour
With 335/ft (1100/M) lumens at 3W/ft (10W/M) and a 120° beam, this strip offers generous, even illumination for under-cabinet task lighting as well as indirect cove lighting. Its high CRI of more than 90 and excellent colour consistency make wood, stone, fabrics and merchandise look true to life. The 4000K neutral white is a versatile choice for kitchens, laundry rooms, bathrooms, offices and stores. The strip is dimmable with compatible low-voltage dimming power supplies.

Technical specifications
SKU: LS-FLI-9B-12-480-4K
Voltage: 12V DC
Wattage: 3W/ft (10W/M)
Lumen output: 335/ft (1100/M)
Colour temperature: 4000K
Beam angle: 120°
LED density: 146 LEDs/ft (480LEDs/M)
Cut increment: 1" (25mm)
Roll length: 16.4' (5M)
IP rating: IP22
CRI: >90
Operating temperature: -25 to +60°C (-13 to 140°F)
Lifespan: +65,000 hours
Lead wire: 24" (60cm) on both ends
Mounting: double-sided adhesive tape on the back
Certification: c UL us
Warranty: 5-year

Channels and installation
The spec sheet lists a range of aluminium LED profiles designed to be combined with this strip. The LL12 standard frosted channel and the LL13 wide slim frosted channel are compatible with all connectors, while the LL10 slim recessed frosted channel suits recessed installations. Cut only at the marked 1" (25mm) points, clean the surface before applying the adhesive backing, and use a 12V constant voltage power supply sized for the total load. With its IP22 rating, this is an indoor product.

Documentation
The complete spec sheet, including ordering codes, connectors and channels, is available in the Documentation tab of this page.
