LED STRIP 19.2W/M - LCLS24V-96W-40K-IP22-30M

Name: LED STRIP 19.2W/M - LCLS24V-96W-40K-IP22-30M
Brand: LEDCO
SKU: LCLS24V-96W-40K-IP22-30M
Price: 522.97 CAD
Availability: InStock

SKU: LCLS24V-96W-40K-IP22-30M

Brand: LEDCO

Turn a plain ceiling cove, a run of cabinets or a retail display into something people actually notice. This LED strip is a high-output 24V flexible tape — what shoppers usually call LED strip lights, LED light strips, LED strip lighting or LED lighting strips — built for real residential and commercial projects, not for decoration only. SKU LCLS24V-96W-40K-IP22-30M gives you a generous 30 m spool of continuous tape light that you cut to size on site, so a kitchen valance, a staircase, a bulkhead and a reception desk can all come out of the same roll and match perfectly. It hides in coves and aluminum channels, tucks under shelves and counters, and turns into the clean line of LED ceiling strip light everyone is looking for.

Under the silicone-free 10 mm PCB you get 128 Epistar 2835 SMD chips per metre drawing 19.2 W/m (±10%) at an efficiency of 120 lm/W, with a 120º beam angle that blends the dots into a smooth wash. The colour temperature is 4000K — a crisp, neutral white that keeps whites clean and finishes honest — and the CRI 90+ rendering makes wood grain, paint, food and merchandise look the way they should. It runs on 24V DC, it is dimmable, the PCB uses a heavy 3 oz copper build, cut size is 62.5 mm (8 LEDs), maximum run is 10 m per feed, it is UL listed, IP22 rated for indoor use, and rated for 50 000+ hours of life.

Put it to work in kitchens under upper cabinets, in bathrooms around a mirror, in basements and hallway coves, in closets and pantries, in stairwells, and in commercial spaces like boutiques, bakeries, salons, offices and showcase millwork. For Canadian homes and businesses, the IP22 rating means dry indoor locations — for damp or outdoor runs, choose an IP66 version such as the LED strip 19.2W/M 24V 96W 30K IP66. Prefer a warmer glow? The same tape is offered as LED strip 24V 19.2W/M IP22 (30K) or LED strip 24V 19.2W/M IP22 (27K). Roll it out and light your project properly.

Built for continuous, dot-free light
This is a high-density tape: 128 Epistar 2835 SMD chips per metre on a 10 mm wide flexible PCB. That density is what kills the "string of dots" effect — with a 120º lighting angle and a diffuser or aluminum channel, you get an even line of light instead of hot spots. The circuit board is built with 3 oz copper, a heavier copper weight that helps carry current and move heat away from the diodes over long runs, which matters when you are pushing 19.2 W/m. Cut marks fall every 62.5 mm (8 LEDs), so you can trim the tape to a shelf, a cabinet or a stair nosing without wasting material.

Light quality you can trust
The 4000K neutral white is the workhorse colour temperature for kitchens, bathrooms, offices and retail: brighter and more modern than warm white, without the clinical edge of a cool daylight tone. Paired with CRI 90+, colours stay true — skin tones in a bathroom mirror, produce in a display case, fabric in a boutique, stain on custom millwork. Efficiency is rated at 120 lm/W, so you get serious output per watt and a rated life of 50 000+ hours, which keeps maintenance calls and re-lamping off your schedule.

Technical specifications
SKU: LCLS24V-96W-40K-IP22-30M
Chip: Epistar 2835 SMD
LEDs per metre: 128 pcs
Power: 19.2 W/m ±10%
Efficacy: 120 lm/W
Colour temperature: 4000K
CRI: 90+
Beam angle: 120º
Voltage: 24V DC
Dimmable: Yes
PCB width: 10 mm
PCB thickness: 3 oz
Maximum run length: 10 m
Cut size: 62.5 mm (8 LEDs)
Protection rating: IP22
Certification: UL
Lifespan: 50 000+ hours

Wiring, dimming and installation
The tape runs on 24V DC, so it needs a compatible low-voltage driver or power supply sized for your total load: multiply 19.2 W by the number of metres installed and add headroom. Respect the 10 m maximum run per feed — beyond that, run a new home run from the power supply rather than extending the same length of tape, to avoid voltage drop and a dimmer end. The strip is dimmable through the driver/control system, which lets you set a bright work level under cabinets and a soft evening level in the same space. Clean and dry the surface before applying, mount in an aluminum LED channel wherever the tape is visible or runs long — the extrusion diffuses the light and acts as a heat sink — and keep cuts on the marked lines so the solder pads stay usable.

Applications, options and documentation
Typical jobs: under-cabinet kitchen lighting, cove and tray ceilings, backlit bathroom mirrors, closet and pantry shelving, stair and corridor accents, reception desks, display cases, bar fronts and store shelving. The IP22 rating keeps this one in dry indoor locations; for damp, wet or exterior work pick an IP66 tape such as the LED strip 9.6W/M 24V 48W 30K IP66. Need less output for a subtle accent? See the LED strip 24V 4.8W/M IP22 (30K). For adjustable white, the LED strip 20W/M 24V 100W IP22 (CCT) is a good alternative, and colour-changing projects can use the LED strip 14.4W/M 24V 72W RGB IP22. The full technical PDF spec sheet for this model is in the Documentation tab.

Technical Files
