LED POWER SUPPLY - 24W

Built for indoor and outdoor LED projects
This waterproof LED driver (LCPSLCO-12V-24WIP67) has an IP67-rated design for indoor or outdoor installations. Its compact body measures 182 x 29 x 20 mm (L x W x H), or 7.165 x 1.142 x 0.787 in, and weighs 0.200 kg, so it tucks neatly into a soffit, behind a planter, under a cabinet or inside a sign. Cooling is handled by free air convection, and units go through a 100% full-load burn-in test, a good sign of long-term reliability for your LED power supply.

Stable 12V output and complete protection
As a constant-voltage LED driver, it supplies 12V DC with a ±0.5V tolerance and a rated current of 2A, for a rated power of 24W. It accepts a wide 100-265V AC input at 50/60 Hz and runs at a typical efficiency above 83%, which means less wasted energy and less heat. Three protections are built in: a short circuit puts the unit in hiccup mode and it recovers automatically once the fault is removed; overload protection kicks in at 145-160% above peak rating; and over-temperature protection shuts the output down until the driver is powered on again. The input-output and input-ground withstand voltage is 1.5 kV AC.

Installation and compatibility
This driver is intended for 12V constant-voltage LED lighting, such as 12V LED strips and modules. Add up the wattage of the lights you connect and keep the total comfortably below 24W for a cooler, longer-lasting installation; for longer runs, split the lighting into zones with one driver each. It is non-dimmable, so use it for lighting that runs at full brightness and not with a dimmer. It works in ambient temperatures from -30°C to +50°C and in 20-99% RH non-condensing humidity. For a 24V strip, use the 24W 24V non-dimmable power supply, or step up to the 60W 24V non-dimmable power supply for bigger 24V projects. Have a licensed electrician make the line-voltage connection.

Applications and documentation
Typical uses include outdoor LED strip lighting under deck railings and steps, soffit and fascia accents, garden features, illuminated signs, bathroom vanities and coves, kitchen under-cabinet lighting, retail shelving and display cases. Suitable for residential and commercial projects, it is CE and RoHS certified and backed by a 3-year warranty. The technical spec sheet (PDF) is available in the Documentation tab.

Technical specifications
Model: LCPSLCO-12V-24WIP67
Output: 12V DC constant voltage, ±0.5V
Rated current: 2A
Rated power: 24W
Input: 100-265V AC, 50/60 Hz
Efficiency: above 83% (typical)
Protections: short circuit, overload, over-temperature
Operating temperature: -30°C to +50°C
Rating: IP67
Cooling: free air convection
Dimensions: 182 x 29 x 20 mm
Weight: 0.200 kg
Dimming: non-dimmable
Certifications: CE, RoHS
Warranty: 3 years
