LED ALUMINUM PROFILE #90 - LCPROF-90-16FT-LENS-OPAQ

Name: LED ALUMINUM PROFILE #90 - LCPROF-90-16FT-LENS-OPAQ
Brand: LEDCO
SKU: LCPROF-90-16FT-LENS-OPAQ
Price: 124.97 CAD
Availability: InStock

SKU: LCPROF-90-16FT-LENS-OPAQ

Brand: LEDCO

Give every corner a smooth, continuous glow with this LED aluminum profile from the 90 series, supplied in a 16-foot length with an opaque lens (LCPROF-90-16FT-LENS-OPAQ). Whether you call it an aluminum extrusion, an LED channel or an aluminum profile for LED strip lighting, its job is simple: hold your LED strip in a corner and send the light out at 45°, right where it is needed. It is a natural fit for commercial displays, cosmetics counters, bars, bookcases and cabinets, in residential and commercial projects alike. It is also known as an LED corner channel, the right choice when a flat channel would point the light the wrong way.

Behind the minimalist look is a profile made of 6063-T5 aluminum alloy that increases heat dissipation, which increases the lifetime of your LED strip. The technical drawing shows a compact 15.6 mm (0.614 in) by 17.5 mm (0.689 in) cross-section, and the application guide calls for LED strips of 10 mm (3/8 in) or less. Paired with the opaque lens, the design delivers light without hot spots, while the long lens-fitting system and its enhanced mechanical fit keep the lens in place for the long term. The 90 series is covered by a 3-year warranty.

In a cosmetics boutique in Toronto, a pharmacy in Sherbrooke or a family room in Winnipeg, the 16 ft length lets you cover long corners with a single piece. Want a darker look? The black 16 ft profile with opaque lens is the same profile in black. Prefer a frosted lens? Choose the 16 ft profile with frosted lens. Bring your corner lighting project to life today: measure your corners, pick your LED strip and let the profile do the rest.

Sold separately
To complete the installation, add:
End cap: LCENDCAP-STAND-90, LCENDCAP-STAND-90-BK, LCENDCAP-STAND-90-H, LCENDCAP-STAND-90-H-BK

Corner lighting, done right
Corners are often the darkest spots of a display or a room. The 90 series LED corner profile solves that: it installs in the angle between two surfaces and offers lighting with a beam oriented at 45 degrees, without hot spots. In POP displays, it maximizes the appeal of products while maintaining a minimalist style. The LCPROF-90-16FT-LENS-OPAQ model adds an opaque lens and comes in a 16 ft length for long runs.

Materials and light quality
The profile is made of 6063-T5 aluminum alloy, which increases heat dissipation; in practice, using an aluminum LED channel increases the lifetime of your LED strip. The opaque lens hides the individual LEDs from view and, together with the profile design, gives uniform light without hot spots. A long lens-fitting system and a new, enhanced mechanical fit for the lens maximize long-term durability. Because the strip sits inside the channel, the installation also looks neater: no visible adhesive backing, no exposed circuit board, just a clean line.

Installation
Use an LED strip 10 mm (3/8 in) wide or narrower. The series spec sheet lists a 45° corner bracket or double-face mounting tape for mounting, and end caps without a hole, with a hole or one of each. A simple sequence works well: cut the profile and lens to the length of your corner, clean the channel, apply the strip, fit the lens, then close the ends with the end caps. For a long 16 ft run, plan where the power feed will come in before you start, so the wire exits neatly through an end cap with a hole.

Technical specifications
SKU: LCPROF-90-16FT-LENS-OPAQ
Series: 90, corner mounting
Length: 16 ft
Lens: opaque
Beam: oriented at 45°
Cross-section: 15.6 mm (0.614 in) / 17.5 mm (0.689 in)
LED strip: up to 10 mm (3/8 in) wide
Material: 6063-T5 aluminum alloy
Use: residential and commercial
Warranty: 3 years

Ideas and documentation
Line the corners of a jewellery showcase, highlight bottles behind a bar, light the top corner of open shelving or run a continuous line along a kitchen backsplash corner. Designers also use it to trace the edge of a reception desk or to light the inside corner of a wardrobe. From Vancouver to Halifax, this aluminum profile gives any LED strip lighting project a finished look. The spec sheet is in the Documentation tab. For shorter corners, the 8 ft profile with opaque lens uses the same design.

Technical Files
