LED ALUMINUM PROFILE #90 - LCPROF-90-16FT-BK-LENS-OPAQ

A corner profile that puts light where you need it
The 90 series is an LED corner profile designed to sit in the angle between two surfaces and project light at 45 degrees. Instead of pointing straight down, the beam is oriented toward the area you want to highlight: the back of a display, the face of a shelf or a countertop. This design excels in point-of-purchase stands, where it maximizes the appeal of products while keeping a minimalist style. This version, LCPROF-90-16FT-BK-LENS-OPAQ, pairs a black aluminum profile with an opaque lens in a 16 ft length.

Light quality and heat management
An aluminum extrusion is more than a cover: made of 6063-T5 aluminum alloy, this profile increases heat dissipation, and using it increases the lifetime of your LED strip. The design aims for uniform light without hot spots, and the opaque lens turns the strip into a continuous, clean line of light rather than a row of bright dots. The long lens-fitting system and improved mechanical fit hold the lens securely over time, even in busy shops where displays are handled and cleaned often.

Installation tips
The profile accepts LED strip lights up to 10 mm (3/8 in) wide. Clean the inside of the channel, apply your strip along the base, then fit the lens into place. The 90 series spec sheet lists two mounting methods, a 45° corner bracket or double-face mounting tape, as well as end caps with or without a hole for the wire; check the Documentation tab to plan your hardware. For the 16 ft length, measure your corner carefully, cut the profile and lens with a fine-tooth saw, then deburr the edges before installing the strip.

Technical specifications
SKU: LCPROF-90-16FT-BK-LENS-OPAQ
Series: 90 (corner profile)
Length: 16 ft
Finish: black aluminum
Lens: opaque
Beam orientation: 45°
Cross-section (drawing): 15.6 mm (0.614 in) x 17.5 mm (0.689 in)
LED strip width: 10 mm (3/8 in) or less
Material: 6063-T5 aluminum alloy
Warranty: 3 years

Applications and documentation
Use this black LED profile to outline shelving in a boutique, light the back corner of a bar display, brighten the inside of a closet or accent kitchen cabinets anywhere in Canada. It suits residential and commercial projects alike. The technical spec sheet, with the drawing and ordering details, is in the Documentation tab. For matching runs, see the 16 ft profile with opaque lens or the black profile with frosted lens.
