LED PUCK LIGHT #2000 LOUVER

Name: LED PUCK LIGHT #2000 LOUVER
Brand: LEDCO
SKU: LCPK2000P-1W-3000K-BS
Price: 30.97 CAD
Availability: InStock

SKU: LCPK2000P-1W-3000K-BS

Brand: LEDCO

Tiny fixture, big difference: this LED puck light slips into a cabinet, a stair nose or a deck board and throws a clean, controlled beam exactly where you need it. Known as a puck light, mini recessed puck, rondelle or under cabinet light, it is the little workhorse people look for when they search "led puck lights", "kitchen lights puck" or "bathroom cabinet light". This version, SKU LCPK2000P-1W-3000K-BS, wears a louver trim (persienne) in brushed stainless, so the light source is shielded and aimed forward rather than straight into your eyes — perfect for toe-kicks, shelf edges, closet interiors, display cases and low-level guide lighting.

Inside that small body you get 125 lumens from just 1 watt, the equivalent of a 20-watt incandescent, with a tight 25° projection angle for crisp pools of light. It runs on 12/24 V DC low voltage, is dimmable, and holds a power factor of +90 with a CRI greater than 80, so wood, stone and merchandise keep their true colour. The warm 3000K colour temperature is the cozy, inviting white most homeowners want in a kitchen or bathroom. Rated IP67, it shrugs off splashes, dust and washdowns, and its 25,000-hour lifespan plus 3-year warranty mean you install it once and forget about it. The fixture measures 50 mm / 1.967" across, and it drops into a 35 mm / 1.378" cutout — a single hole saw and you are done.

This mini LED puck earns its keep in kitchens (under upper cabinets, over a sink run, inside glass display cabinets), bathrooms and vanities, walk-in closets, pantries, stair risers, mudroom benches, and outside on decks, patios, docks and stone walls where Canadian winters demand a sealed fixture. Retailers love it for jewellery cases, wine displays and reception desks. Need a different look or colour? Pair or match it with the LED puck #2000 persienne in black, the cooler 4000K brushed stainless louver version, the colour-changing RGB brushed stainless louver puck, or the round 1-side puck light from the same PK2000 family. Grab a few, plan your layout, and light up the details.

Built small, built to last
The PK2000 platform (model LCPK2000) was designed for tight millwork and finished surfaces. The visible face measures 50 mm / 1.967" and the body behind it stays compact, so it hides inside a cabinet gable, a stair stringer or a deck frame without eating your usable space. On this SKU the trim is the louver (persienne) style in brushed stainless — a shielded, slotted front that cuts direct view of the diode and pushes the light forward. The whole assembly is rated IP67, which is why the same puck works just as happily under a bathroom vanity as it does in an exterior stair riser exposed to rain and snowmelt.

Light quality you can actually see
You get 125 lumens of usable output from 1 watt — the visual punch of a 20-watt incandescent at a fraction of the draw, with up to 80% less energy than traditional halogen or incandescent accent lamps. The 25° beam keeps the light tight and intentional: defined scallops on a backsplash, a bright pool on a countertop, a soft wash on a stair tread. With a CRI above 80, whites read white and wood grain reads warm rather than muddy, and the 3000K warm white tone flatters cabinetry, tile and skin tones. A power factor of +90 means clean, efficient operation on your low-voltage circuit.

Technical specifications
Model: LCPK2000
SKU: LCPK2000P-1W-3000K-BS
Voltage: 12/24 V DC
Consumption: 1 Watt
Light intensity: 125 lumens
Incandescent equivalent: 20 watts
Colour temperature: 3000K
CRI: greater than 80
Projection angle: 25°
Power factor: +90
Dimmable: yes
Protection rating: IP67
Lifespan: 25,000 hours
Cutout size: 35 mm / 1.378 inches
Fixture face: 50 mm / 1.967"
Trim: louver (persienne), brushed stainless
Warranty: 3 years

Wiring and installation
Because it is a low-voltage 12/24 V DC fixture, this puck needs a DC driver or power supply sized for the total wattage of the run — at 1 watt each, you can chain a generous number of pucks on a modest supply, which is exactly why designers use them in long cabinet runs and stair sequences. Drill a 35 mm / 1.378" hole, feed the leads, seat the puck and you are finished; no visible hardware, no bulky housing. It is dimmable, so pair it with a compatible low-voltage DC dimmer to set a bright task level for cooking and a low glow for evenings. Keep polarity consistent along the run and mount pucks toward the front edge of a cabinet so the beam lands on the counter instead of the backsplash.

Where it works and what it pairs with
Think kitchen under cabinet lighting, glass display and jewellery cases, wine cellars, bar fronts, bathroom vanity kicks, closet shelving, pantry interiors, stair risers, headboards, deck steps and garden walls. Contractors use the louver trim wherever a guest's eye line meets the fixture — low mounting heights, seating areas, corridors. Mix finishes and temperatures across a project with the 4000K black louver puck, the RGB black louver puck for colour scenes, or step up to a wider spread with the round 1-side puck in 4000K. The full technical spec sheet (PDF), including the technical drawing and the complete trim and colour ordering guide, is available in the Documentation tab — handy for submittals and for matching finishes later in the job.
