Designed to disappear into white cabinetry
The LED PUCK #200 in white is a compact, round recessed puck light meant for the underside of cabinets, shelves and display units. Its white finish visually merges with white or light-painted cabinetry, so when the light is off you barely see it, and when it is on, all you notice is the glow. The fixture fits a 42 mm cutout (1.653"), which keeps installation clean: one hole, the puck seated in place, and a tidy result that suits both new builds and kitchen refreshes.
Balanced, efficient light
With 250 lumens for just 3 watts, the PK200 is an efficient way to add task light exactly where it counts. Its 4000K neutral white tone gives a crisp, modern look that works with white quartz, marble-look surfaces, light woods and pale paint colours. The 45° beam angle creates a defined pool of light on the counter, and the CRI above 80 renders colours faithfully, which matters when you are cooking, sorting laundry or choosing an outfit. Dim it down in the evening for a soft, welcoming ambiance.
Installation and electrical details
The puck operates on DC 12V, so it is powered through a compatible 12V DC LED driver that converts household current; it must never be wired straight to line voltage. For dimmable installations, use a driver and dimmer rated for dimmable 12V LED loads. Rated IP20, it is made for dry indoor locations like cabinets, shelving, closets and display furniture. The spec sheet notes a working temperature of 40 °C at a room temperature of 25 °C. A good practice is to map out the pucks, the wire runs and a ventilated, accessible spot for the driver before drilling, then have an electrician complete the line-voltage connection.
Technical specifications
SKU: LCPK200-12V-40K-WH
Finish: white
Input voltage: DC 12V
LED power: 3 W
Lumen output: 250 lm
Colour temperature: 4000K
CRI: above 80
Beam angle: 45°
IP class: IP20
Dimmable: yes
Cutout size: 42 mm (1.653")
Lifespan: 25,000 hours
Warranty: 3 years
Project ideas
Line the underside of upper cabinets for kitchen under cabinet lighting, light the shelves of a walk-in pantry, add a bathroom cabinet light inside a medicine cabinet, or brighten the folding counter of a laundry room. Home offices with built-in shelving, display niches in a child's bedroom and retail counters with glass cases are other great spots. The spec sheet, with the technical drawing and all specifications, is available in the Documentation tab for your contractor or cabinetmaker.
