ATHENA PAR30 SPOTLIGHT - LCTL-ATH-PAR30-BS

Name: ATHENA PAR30 SPOTLIGHT - LCTL-ATH-PAR30-BS
Brand: LEDCO
SKU: LCTL-ATH-PAR30-BS
Price: 37.97 CAD
Availability: InStock

SKU: LCTL-ATH-PAR30-BS

Brand: LEDCO

Make a statement on your track with the Athena PAR30 spotlight, a line voltage track light head that pairs a larger PAR30 lamp with an adjustable, lightweight, high-styled body. The exposed lamp design lets you choose the beam and colour you want, then aim it precisely at a display, a mural, a bar shelf or a dining table. Shoppers also call it a track lighting head, a PAR30 track light or a track spotlight; this version, LCTL-ATH-PAR30-BS, joins the black and white Athena PAR30 heads to give designers one more option for coordinating fixtures across a project.

Built of die cast aluminum for superior strength and rigidity, the head features softened edges that keep its profile low and elegant. Its porcelain socket holds 120V PAR30 lamps, 75 watts max, with rear load lamping, and an included high temperature glass shield is mounted to the front of the fixture. A vertical rotation of 90° and a horizontal rotation of 330° provide a wide range of aiming possibilities, and the fixture assures a secure lock on the angle position. It is dimmable with electronic line voltage rated dimming controls only, runs on a 120V / 60Hz input with a 120V output and a 75W maximum load, and is cULus listed.

Choose an efficient PAR30 LED bulb and this PAR30 track light becomes an energy-saving workhorse that uses a fraction of the power of halogen: a spot for a single sculpture, a flood for a wall of wine bottles, warm white for a hotel lounge, neutral white for a showroom. Think of a St. John's pub, a Gatineau furniture showroom or a Kitchener brewery taproom. Need other finishes? See the Athena PAR30 spotlight in black or the Athena PAR30 spotlight in white. Confirm the connector style for your track and give your space the spotlight it deserves!

Design and construction
The ATHENA (model PAR221/30 on the spec sheet) is an adjustable, lightweight, high-styled, exposed lamp design, line voltage track lighting fixture sized for PAR30 lamps. Its body is constructed of die cast aluminum, which provides superior strength and rigidity, and softened edges add up to the low profile aesthetic design. This version carries the code LCTL-ATH-PAR30-BS, alongside the black and white Athena PAR30 heads; the ordering guide of the series lists black, brushed nickel and white trim finishes.

Lamping and light quality
ATHENA provides rear load lamping into a porcelain socket for 120V PAR30 lamps, 75 watts max, and a high temperature glass shield is included, mounted to the front of the fixture. The directional light source allows for special aiming, and the beam, colour and output come from the lamp you choose. A PAR30 LED lamp is a natural fit: it lets you swap from a narrow spot to a wide flood as displays change, and dimmable models make it easy to shift from bright daytime light to a softer evening mood in a restaurant or a living room.

Electrical and installation details
The fixture is made for a 120V / 60Hz input and a 120V output, with a 75W maximum load, and it is cULus listed. It is dimmable when used with electronic line voltage rated dimming controls only; pair dimmable lamps with a suitable dimmer. The fixture provides vertical rotation of 90° and horizontal rotation of 330°, then assures a secure lock on the angle position. The spec sheet's connector compatibility chart shows the connector styles offered for the series: compare it with your track before installing, and note that accessories should be ordered separately. Turn off the breaker before adding or moving heads, and have a qualified electrician install the track and its power feed.

Technical specifications
SKU: LCTL-ATH-PAR30-BS
Line: ATHENA line voltage track fixture (PAR221/30)
Body: die cast aluminum, softened edges, low profile
Lamp: 120V PAR30, 75 watts max, rear load
Socket: porcelain
Front shield: high temperature glass, included
Rotation: 90° vertical, 330° horizontal
Electrical: 120V / 60Hz input, 120V output, 75W maximum load
Dimming: electronic line voltage rated dimming controls only
Certification: cULus listed
Trim finishes in the series: black, brushed nickel, white

Applications and documentation
Run a line of these track light heads above the tables of a pub, across the display walls of a furniture showroom or along the tanks of a brewery taproom; at home, light a fireplace wall, a piano or a reading corner. For higher ceilings or longer throws, the Athena PAR38 spotlight (LCTL-ATH-PAR38-BS) takes a larger PAR38 lamp. The spec sheet, with the technical drawing, connector compatibility chart and ordering guide, is available in the Documentation tab.
