LED RECESSED 4" DLS ROUND - 9W - 5CCT BLACK

Name: LED RECESSED 4" DLS ROUND - 9W - 5CCT BLACK
Brand: LEDCO
SKU: LCDL-DLS4-5CCT-9W-BK
Price: 23.97 CAD
Availability: InStock

SKU: LCDL-DLS4-5CCT-9W-BK

Brand: LEDCO

Give any room a clean, modern ceiling without tearing it apart. This 4" round LED recessed light — what most people call a pot light, a slim downlight or a round LED ceiling light — packs a swivel gimbal head into an ultra-slim panel, so you get real directional control in a fixture barely thicker than the drywall it sits in. The frosted lens softens the diode so the beam feels smooth and even instead of spotty, and the aimable head lets you wash a wall, highlight a backsplash or point light exactly where the work happens. It is a favourite for both residential recessed lighting and commercial recessed lighting jobs, in new construction or in a remodel where there is almost no plenum space above the ceiling.

Model LCDL-DLS4-5CCT-9W-BK draws just 9W and puts out 680 lm at 2700K, 700 lm at 3000K, 750 lm at 3500K, 760 lm at 4000K and 740 lm at 5000K — five colour temperatures you select with the toggle switch right on the junction box, so one box on the truck covers warm living rooms and crisp kitchens alike. The 40° beam angle keeps the light controlled, CRI >80 keeps skin tones, paint colours and merchandise looking true, and the power factor of >0.94 keeps the electrical side tidy. It runs on 110-130VAC, is Triac base dimmable, carries a black trim, is approved for damp locations and is cETLus certified, with a 3 years warranty. The panel measures 4.92" (125 mm) in diameter and only 1.89" (48 mm) deep, into a 4.25" (108 mm) cutout.

Use it down a hallway, across a basement ceiling, over a kitchen island, in bathrooms and covered entries thanks to the damp location rating, or through an office, clinic or retail floor where an even grid of 4 inch recessed lights keeps everything looking sharp. Canadian renovators love it for older homes with shallow joist bays and for finished basements with strict ceiling height. Need the same look in other sizes or a different style of downlight? Pair it with the Round commercial LED recessed 4", step up to the Round commercial LED recessed 6", or go low-voltage with the Slim LED recessed 12/24V 4" DLF round. Plan your layout, grab your count and light the whole project with one clean look.

Built slim, built to aim
This is a CCT 4" swivel gimbal panel light, and that gimbal is the difference. Instead of a fixed downward beam, the head swivels inside the trim so you can angle the light toward artwork, a stone feature wall, a reading chair or a workbench. The panel body is 4.92" (125 mm) across and just 1.89" (48 mm) deep, with a black trim that disappears into dark ceilings and reads as a deliberate design choice in white ones. Because the housing is so shallow, it drops into ceilings where a traditional can simply will not fit — shallow joist bays, bulkheads, soffits and renovated basements.

Light quality and colour selection
Five colour temperatures are built into one fixture: 2700K, 3000K, 3500K, 4000K and 5000K, chosen with the toggle switch on the junction box before you seat the fixture. Upper position gives 2700K, second position 3000K, middle position 3500K, fourth position 4000K and lower position 5000K. Output follows the setting: 680 LM at 2700K, 700 LM at 3000K, 750 LM at 3500K, 760 LM at 4000K and 740 LM at 5000K, all from 9W. A CRI of >80 keeps colours honest, and the 40° beam angle gives you a controlled pool of light that layers nicely when fixtures are spaced evenly across a ceiling.

Technical specifications
Model: LCDL-DLS4-5CCT-9W-BK
Power: 9W
Colour temperature: 2700K / 3000K / 3500K / 4000K / 5000K tunable
Lumens: 680 / 700 / 750 / 760 / 740 LM
Beam angle: 40°
CRI: >80
Input voltage: 110-130VAC
Power factor: >0.94
Trim colour: Black
Dimming: Triac base dimmable
Location approved: Damp location
Certification: cETLus
Warranty: 3 years
Cutout size: 4.25" (108 mm)
Panel diameter: 4.92" (125 mm)
Panel depth: 1.89" (48 mm)
Junction box: length 4.25" (108 mm), width 2.4" (60 mm), height 1.375" (35 mm)

Wiring, dimming and installation
Cut a 4.25" (108 mm) hole, make your connections in the included junction box, set the colour temperature toggle, then push the fixture up until the spring clips grab the drywall. It runs on standard 110-130VAC line voltage and is Triac base dimmable; the spec sheet lists compatible dimmers including Lutron S-603P, CTCL-153P, TG600P, DV600P, LG600P, SCL-153P, MAW-600, LGCL-153P, 7SCL-153P, 600PH, DV-600P, 6838, CTELV-303P, CTCL-153PD, and Leviton 6633-P, 1C33L1, 6674 and 6838-series style controls — matching a listed dimmer is the surest way to get smooth, flicker-free low end. A 4 inch mounting plate (LCPLATE-414) is available when you are working with a ceiling opening that needs support. Always cut the power at the panel first, and have a licensed electrician handle the connection if you have any doubt.

Applications, compatible products and documentation
Think condo hallways on a tight ceiling, a finished basement with a bulkhead over the ductwork, a bathroom or covered porch where the damp location rating matters, or a boutique where aimed beams put the product in the spotlight. For larger rooms and commercial ceilings, the family continues with the Round commercial LED recessed 8" and the Round commercial LED recessed 10", while cabinetry, millwork and vehicle-style low-voltage runs are better served by the 12/24V LED recessed 4" DLF flat. The full technical PDF for this model is in the Documentation tab, with the technical drawing, the colour temperature switch positions, the trim options and the complete compatible dimmer list — worth printing before your rough-in.
