What is inside the sleeve
This 22 gauge RGB wire groups a black, a green, a red and a blue conductor inside a white sleeve. Each conductor corresponds to a line of an RGB LED strip, so every colour channel travels on its own path from the controller to the farthest section. Bundled this way, the run looks like a single neat cable rather than loose strands, which matters wherever part of it remains visible: across the top of a cabinet, along a soffit or inside an open cove. The white sleeve also makes the wire easy to spot when you open a cabinet years later for maintenance.
Planning the dark gaps
The wire is made for planned distances between lighted areas. Start with a sketch: mark where the light should begin and end, then measure each section that must stay dark, such as the width of a range hood, a stove fan, a window or a doorway. Cut an LED strip jumper for each gap from the 10 m length, leaving a little slack at each end so you can work comfortably. Connect each end to the strip with solder or a suitable connector, always keeping each colour on the matching pad, and test every colour before you close a valance or reinstall a cabinet part. If several jumpers share the same run, label them with small tags so future service is quicker.
Extending a strip to its controller
The other classic use is the LED strip extension. When the RGB controller sits inside a cabinet, a closet or a utility room, this wire carries the colour circuit to the exact point where the light begins, so the strip itself starts where you want it to. Route the wire along a clean path, away from sharp edges and from the heat of a cooktop, and fasten it so doors and drawers cannot pull or pinch it. Where it passes through walls or ceilings, follow your local building code and have a qualified electrician confirm the installation.
Projects that come alive
Kitchen cabinets on both sides of a hood, a television wall with lit shelves on each side, a staircase with lit landings, a basement bar, a clinic reception desk, a restaurant banquette or a retail display with separate lit niches: in each case, the RGB wire links the lit sections so the same controller drives the whole scene in harmony. Retail designers appreciate that every niche changes colour in step with the others. It suits residential and commercial work and helps contractors deliver a finished, professional result without lighting what should stay dark.
At a glance
Wire type: RGB wire for LED strips
Gauge: 22 AWG
Length: 10 m
Made for: RGB LED strips
