Built to disappear into the ceilingThe ENDURA SP II uses a pressure die-cast aluminum body for better thermal management, which is what keeps an edge-lit panel this thin running cool and stable over the long term. The light source sits at the edge and is spread across a premium-grade opal diffuser, so you get an even, glare-free wash instead of a hot spot staring back at you. The slim profile — just 1.30" high on the 6" model — is made for low-depth installations where a traditional housing simply won't fit: shallow joist bays, furred-down bulkheads, condo slabs, basement ceilings. The white metal trim gives it a crisp, finished edge that suits modern and traditional interiors alike.
Light quality and colour selectionWith 5 field-selectable CCT options (27K, 30K, 35K, 40K and 50K), one fixture covers every room in the project. Set it warm for living rooms and bedrooms, neutral for kitchens and bathrooms, cooler for garages, offices and work areas — the choice is made on site, so you're never stuck ordering the wrong colour. The 80 CRI output renders colours naturally, and the 120° beam angle gives broad, comfortable coverage that lets you space fixtures generously without dark gaps between them.
Technical specificationsModel: EDA-SP2/6/12W/MK5/120-347V/WH/0-10V
Wattage: 12W
Lumens: 1,100 lm
CCT: 27K / 30K / 35K / 40K / 50K field selectable
CRI: 80
Input voltage: 120-347V auto-sensing driver
Beam angle: 120°
Dimming: 0-10V and TRIAC compatible
Rated life: 50,000 hours
Dimensions (D × H): 6.93" × 1.30"
Cut-out: 6.3"
Location: Wet location rated (indoor)
Operating temperature: -20˚C to +40˚C
Mounting: Recessed with spring clamps
Finish: White
Warranty: 5 years
Electrical and installationThe 120-347V auto-sensing driver is a real time-saver for contractors: the same box works on a 120V residential circuit or a 347V commercial feed without ordering a separate version. Cut a 6.3" hole, make your connections, fold in the spring clamps and push the panel up — it holds itself flat against the ceiling. Because the unit is IC-rated for direct contact with insulation, it can go straight into insulated ceilings, and the wet location rating (indoor) allows use in bathrooms, over showers and in similar damp spots. For dimming, wire it to a 0-10V control for commercial rooms and meeting spaces, or use a compatible TRIAC dimmer in residential settings; either way the driver operates reliably from -20˚C to +40˚C, handy in Canadian garages, entryways and unheated storage areas.
Applications, compatibility and documentsOffices, malls, hotels and residences are the natural homes for this panel, along with clinics, salons, restaurants, classrooms and retail back-of-house. Lay out a kitchen ceiling on a regular grid, line a corridor, light a stairwell, or replace aging recessed cans one for one. Within the family, the
Endura SP II 4" 8W panel suits closets, small baths and accent rows, while the
Endura SP II 8" 16W panel covers larger open areas. RGD-SP3 trim rings are offered for the 4" and 8" sizes in
black and
brushed nickel for a different look on those models. The full technical spec sheet for this SKU, with the dimensional drawing, polar candela curve and ordering information, is available in the Documentation tab.
