300W, 12V, 5-IN-1 DIMMABLE, TRIAC,100-277V AC IN, 12V DC OUT, WET LOCATION, JUNCTIONBOX POWER SUPPLY

Name: 300W, 12V, 5-IN-1 DIMMABLE, TRIAC,100-277V AC IN, 12V DC OUT, WET LOCATION, JUNCTIONBOX POWER SUPPLY
Brand: LUMENSTARLED
SKU: LS-12V-300D-MLT-CV
Price: 416.97 CAD
Availability: InStock

SKU: LS-12V-300D-MLT-CV

Brand: LUMENSTARLED

Power long runs of LED tape from a single, tidy unit with the LUMENSTARLED LS-12V-300D-MLT-CV. This 300W 12V dimmable LED power supply, also called an LED driver, LED transformer or constant voltage power supply, converts line voltage into a steady 12V DC output for 12V LED strip lights, cove lighting, under-cabinet lighting, shelf and display lighting and illuminated signage. With its built-in junction box, it is made for clean, professional installations in homes and commercial spaces.

The 5-in-1 dimmable design works with TRIAC dimmers, so you can set the perfect light level from a standard wall dimmer for a relaxing living room, an elegant restaurant or a showroom that needs flexible lighting scenes. The 100-277V AC input covers both residential and commercial circuits, which means one model can be specified across many different projects. With 300W of capacity on a constant voltage 12V DC output, it can feed substantial runs of LED tape without multiplying smaller drivers, reducing the number of components to install and maintain. It is rated for wet locations, and the junction box enclosure keeps every wiring connection neatly contained.

Use it for kitchen and bathroom LED strips, cove and tray ceilings, bars, hotel corridors, retail displays, covered patios and exterior architectural accents across Canada. Match it with 12V LED strip lights and keep the total load of your runs within the driver's capacity. Order the LS-12V-300D-MLT-CV and power your next LED project with confidence.

Compatible with
Works with:
LED strip: LS-FLO-1B-12-60-3K, LS-FLO-1B-12-60-5K, LS-FLO-9B-12-320-27K, LS-FLO-9B-12-320-3K, LS-FLI-1B-12-60-3K, LS-FLI-1B-12-60-4K, LS-FLI-1B-12-120-3K, LS-FLI-1B-12-120-CCT

A high-capacity 12V constant voltage driver
The LS-12V-300D-MLT-CV is a constant voltage LED power supply that delivers a 12V DC output. This is the type of driver required by 12V LED tape light and other 12V constant voltage LED products, which expect a stable voltage rather than a fixed current. With a rating of 300W, a single unit can power a large lighting layout, whether that means several strip runs in a kitchen renovation or long lines of cove lighting in a commercial lobby. Fewer drivers also means fewer mounting locations to plan, fewer connections to make and a simpler layout for whoever services the installation later.

Dimming with TRIAC wall dimmers
This dimmable LED driver is a 5-in-1 model compatible with TRIAC dimming, the type of phase-control dimming used by many common wall dimmers. That makes it easy to add smooth light level control to LED strips in living rooms, bedrooms, restaurants, hotel rooms and boutiques. When choosing a dimmer, select a model rated for LED loads and check its compatibility before installation for the best results. Dimmed LED strips create a warm, inviting atmosphere in the evening while still giving full brightness when you need task lighting.

Universal input, junction box design
The 100-277V AC input accepts both residential and commercial line voltages, which simplifies planning for electricians and lighting designers who work on houses, offices, stores and multi-unit buildings. The integrated junction box power supply format keeps the primary and secondary connections enclosed in the driver itself, giving a tidy installation that is easy to inspect and service. The unit is also rated for wet locations, a real advantage for covered outdoor areas and humid spaces.

Technical specifications
SKU: LS-12V-300D-MLT-CV
Power: 300W
Output: 12V DC, constant voltage
Input: 100-277V AC
Dimming: 5-in-1 dimmable, TRIAC
Rating: wet location
Enclosure: junction box

Applications and installation tips
Typical uses include under-cabinet and toe-kick lighting, cove and tray ceilings, stair lighting, backlit shelving, bar and restaurant accents, signage, retail displays and exterior architectural lighting under a roof overhang. Add up the wattage of all LED strips connected to the driver and leave a safety margin rather than loading it to its full capacity. Installation must be carried out by a qualified electrician in accordance with the Canadian Electrical Code and local regulations.
