4" SLM PLUS ROUND - DTW 3K-2K - 12W - IC - DIMMABLE - WHITE - SLM4-12W-DTW-WH

Name: 4" SLM PLUS ROUND - DTW 3K-2K - 12W - IC - DIMMABLE - WHITE - SLM4-12W-DTW-WH
Brand: LITELINE
SKU: SLM4-12W-DTW-WH
Price: 63.97 CAD
Availability: InStock

SKU: SLM4-12W-DTW-WH

Brand: LITELINE

Want the cozy glow of a halogen bulb without the heat, the bulk or the energy bill? Meet the LITELINE SLIMLED PLUS SLM4-12W-DTW-WH, a 4" slim profile recessed downlight — what most people call a pot light or LED ceiling light — built with dim-to-warm technology. Instead of staying the same shade all evening, the colour temperature drops from 3000 K down to 2000 K as you dim it, mimicking the warm, flattering candle-like glow of incandescent lighting. It is a canless, ultra-thin downlight with an integrated LED module and remote driver, so it slips into ceilings where a traditional housing simply will not fit. Perfect for kitchens, living rooms, hallways, bedrooms, bathrooms, covered porches and commercial spaces that need a residential-grade feel.

This fixture delivers up to 620 lumens from a 12 watt LED module, up to 58 lumens per watt, with a typical CRI of 90 so skin tones, wood grain, paint colours and food look true. The body is durable airtight aluminum with UV stable paint and a white PMMA diffuser lens for low glare, with a 110° beam spread that spreads light evenly across a room. It includes a silicone gasket and is suitable for wet locations, indoor or outdoor, and approved for insulated ceilings. The class II electronic driver runs on 100-135V AC, 50/60 Hz, is dimmable with industry standard TRIAC/ELV forward or reverse phase dimmers, and has a 0.99 power factor. Hole cut is Ø 4 1/4" (108 mm), O.D. 4 13/16" (122 mm), I.D. 3" (76 mm). Minimum starting temperature is -40°C (-40°F), projected life is 70% @ 50,000 hrs, it is cETLus certified, Title 24 JA8 compliant, LM79 and LM80 tested, and backed by a lifetime warranty. Finish: white interchangeable magnetic trim.

This downlight shines in new builds and renovations alike — kitchens, basements, condo ceilings, stairwells, restaurant dining rooms, boutiques, clinics and covered entryways that face a real Canadian winter. Two spring loaded clips grip any ceiling material and the slim profile lets you mount under joists or duct work, while an 18" plenum rated FT6 wire with DC 2.1 connector and quick connect push-in terminals make wiring fast. Want a fixed multi-colour version instead? See the SlimLED Plus SLM4-12W-CCT-WH or step up to 6" with the SlimLED Plus SLM6-16W-CCT-WH. Order the SLM4-12W-DTW-WH and give your ceilings that warm, dimmable glow.

Built slim, built to last
The SLIMLED PLUS is engineered around a durable airtight aluminum body finished in UV stable paint, paired with a white PMMA diffuser lens that softens the LED source and keeps glare down. A silicone gasket seals the assembly, which is why this slim LED downlight is rated for wet locations and approved for indoor, outdoor and insulated ceiling installations. The white interchangeable magnetic trim snaps on and off, so you can change the look later without touching the wiring — a real advantage when a client changes their mind about finishes mid-project.

Dim-to-warm light quality
This is the feature people fall in love with. The 12 watt LED module produces up to 620 lumens and shifts its colour temperature from 3000 K to 2000 K as you dim, recreating the amber warmth of an incandescent or halogen lamp at low levels. With a typical CRI of 90, colours stay rich and natural, and the 110° beam spread lays down an even wash of light rather than hot spots. Efficiency reaches up to 58 lumens per watt with a 0.99 power factor, and the projected life is 70% @ 50,000 hrs.

Technical specifications
SKU: SLM4-12W-DTW-WH
Brand: LITELINE
Application: Ceiling Recessed Mount
Approved location: Wet / Insulated Ceilings / Indoor / Outdoor
Wattage: 12W
Lumens: up to 620
Lumens per watt: up to 58
CCT: 3000 K ~ 2000 K
CRI: 90
Beam angle: 110°
Input: 100-135V AC, 50/60 Hz
Dimming: Yes — Forward/Reverse phase / TRIAC/ELV
Driver: 300mA dimmable class II electronic LED driver, extruded aluminum hardwire box
Hole cut: Ø 4 1/4" (108mm)
O.D. / I.D.: 4 13/16" (122mm) / 3" (76mm)
Colour: WH
Power factor: 0.99
Minimum starting temperature: -40°C (-40°F)
Projected life: 70% @ 50,000 hrs
Certification: cETLus
Title 24: JA8
LM79 / LM80: Yes
Warranty: Lifetime

Wiring and installation
Installation is deliberately simple. Two spring loaded clips let the fixture attach to virtually any ceiling material, and because the profile is so slim it can be mounted under joists or duct work where a can housing would never fit. The remote driver sits in an extruded aluminum hardwire box with quick connect push-in terminals, and an 18" plenum rated FT6 wire with a DC 2.1 connector links the driver to the fixture. Cut a Ø 4 1/4" (108mm) hole, feed the driver through, push in your conductors and click the connector — done. Dimming works with industry standard TRIAC/ELV dimmers in forward or reverse phase; Liteline publishes a compatible dimmer list for the SlimLED family.

Applications, compatibility and documentation
Think open-concept kitchens where the lights drop to a warm amber after dinner, master bedrooms and nurseries, basement renovations with tight joist cavities, hallway runs, covered porches and soffits, plus restaurants, salons, boutique hotels and clinics that want residential warmth. Within the SlimLED family you can swap the look using dead-front trim and baffle combinations such as the Shade Mini 4" round trim white/white, the Shade Mini 4" round trim white/semi-specular or the Shade Mini 4" round trim black/black. Accessories including pre-mounting plates, hanger bar kits, vapour barrier extenders, extra large trim rings and a 60" flexible connector are sold separately. The full spec sheet for the SLM4-12W-DTW-WH is available in the Documentation tab of this page.
