7W G24D RETROFIT, HORIZONTAL MTN ORIENTATION, 2700K 120-277V -LED-7322-27K-G2

Name: 7W G24D RETROFIT, HORIZONTAL MTN ORIENTATION, 2700K 120-277V -LED-7322-27K-G2
Brand: LIGHT EFFICIENT DESIGN
SKU: LED-7322-27K-G2
Price: 18.99 CAD
Availability: InStock

SKU: LED-7322-27K-G2

Brand: LIGHT EFFICIENT DESIGN

Still swapping burnt-out PL bulbs every few months? The LED-7322-27K-G2 from Light Efficient Design is the easy way out: a 7W G24d LED retrofit lamp built to drop straight into the compact fluorescent sockets you already have. People call it a PL retrofit lamp, a 2-pin plug-in LED, a CFL replacement bulb or simply a G24d LED — whatever the name, the job is the same. It replaces up to a 26W 2-pin CFL in downlights, wall sconces, stairwell fixtures, washroom lights and decorative pendants, with no rewiring and no new fixture to buy. Its horizontal mounting orientation is made for lamps that sit sideways in the housing, so the light goes where you actually need it instead of into the reflector.

The numbers are simple and honest: 7 watts, 820 lumens, a cozy 2700K warm white colour and a G24d two-pin base. It runs on 120-277V and also works on 208V and 240V, so the same lamp covers homes, condo corridors and commercial panels alike — one part number for the whole building. With 80+ CRI colours look natural on skin, wood and merchandise, and the rated life of 50,000 hours (L70) means far fewer ladder trips. It is suitable for damp environments, can be used in semi-enclosed recessed fixtures, is insect and dust resistant, and operates from -40°F to 104°F — a real advantage in Canadian entryways, unheated vestibules and garages.

This lamp feels right at home in hotel lobbies and corridors, restaurants, clinic waiting rooms, retail displays, offices, apartment hallways, basements and porch fixtures where a soft, incandescent-like glow matters. Contractors doing a floor-by-floor refresh can mix bases without changing strategy: pair it with the 7W G23-2 retrofit 2700K for 13W 2-pin sockets or the 5W GX23 retrofit 2700K for 9W lamps. Prefer a cooler light in the same fixture? See the 3500K version. Check the socket, order the LED-7322-27K-G2, and give your old PL fixtures a second life.

Built for real retrofit work
The LED-7322-27K-G2 belongs to Light Efficient Design's PIN-BASE family of 2-pin PL retrofit lamps, engineered to take over from Type A/B compact fluorescent tubes without touching the fixture. The body is compact — roughly the footprint of the CFL it replaces — with the LED board oriented for horizontal mounting, the position used in most recessed cans, sconces and ceiling-mounted PL housings. The housing is insect and dust resistant, so bugs and debris do not collect inside and dim the output over time, and the lamp is rated suitable for damp environments as well as for use in semi-enclosed recessed fixtures.

Light quality that flatters a space
At 2700K, this is the warm, golden tone people associate with incandescent bulbs — the colour you want in a hotel lobby, a dining room, a waiting area or a residential hallway. Output is 820 lumens from only 7 watts, replacing up to a 26W 2-pin CFL, and the 80+ CRI rendering keeps wood tones, fabrics and complexions looking true. Because it is solid-state, there is no warm-up delay and no fluorescent flicker at start-up: full light the instant the switch is flipped, even in a cold stairwell.

Technical specifications
Part #: LED-7322-27K-G2
Brand: Light Efficient Design
Wattage: 7W
Replaces: up to 26W 2-pin CFL
Lumens: 820
Colour temperature: 2700K
Base: G24d (2-pin)
Mounting orientation: horizontal
Voltage: 120-277V, also works on 208V & 240V
CRI: 80+
Rated life: 50,000 hours (L70)
Operating temperature: -40°F to 104°F
Environment: suitable for damp environments, semi-enclosed recessed fixtures, insect & dust resistant

Installation and compatibility
Installation is about as simple as lighting work gets: cut the power, twist out the old G24d CFL, insert the LED lamp in the same socket and lock it in place. The wide 120-277V input means the identical lamp serves a 120V residential circuit, a 277V commercial lighting panel, or a 208V/240V system, which is why facility teams can standardize on one part number across several buildings. Always confirm your socket: G24d is the two-pin version, and a four-pin G24q socket will not accept this lamp. For sockets of other 2-pin formats in the same retrofit family, the 7W G23-2 retrofit and the 5W GX23 omni-directional retrofit cover 13W and 9W CFL positions.

Applications and documentation
Think condo corridors and stairwells where lamps run around the clock, restaurant washrooms and entry sconces, boutique display niches, dental and medical waiting rooms, church halls, offices and basement rec rooms. Anywhere a warm ambience is part of the experience, the 2700K version earns its place; if a crisper, more task-oriented look suits the room better, the 4000K G24d retrofit or the Flex Color 3000K/3500K/4000K G24d retrofit are direct alternatives in the same fixture. The full technical spec sheet for the LED 7300 / 7311 / 7312 / 7322 series is in the Documentation tab, with the complete ordering table, lumen values and base types for every model in the family.

Technical Files
