Built to take the weatherThe SSL-AL3 is a slim and compact LED area lighter with a pressure die-cast aluminum body, chosen for its thermal management: heat is pulled away from the LEDs so output and colour stay stable season after season. The optic is a UV-resistant prismatic polycarbonate lens in
Type III distribution, the standard choice for pole-mounted
parking lot lighting along drive lanes and property edges. The whole assembly is
IP65 wet location rated with an operating temperature range of -40˚C to +45˚C, so freeze-thaw cycles, road salt spray and summer heat are all part of the job description. The black finish keeps the fixture visually quiet against dark poles and building facades.
Light output and colourField-selectable wattage means the installer sets the fixture on site:
150W, 100W or 70W, producing
15 750, 10 500 or 7 350 lumens. Drop the wattage on poles near a building entrance, run full output at the far corners of the lot — same SKU, same look, one order line. This model is the fixed
2200K version, a warm amber light appreciated where a softer outdoor appearance is preferred, and CRI 80 keeps colours readable for cameras, signage and vehicle identification. Rated life is L80 at 100,000 hours, which is what makes a 5 years warranty and a pole-mounted fixture a sensible combination — nobody wants a lift truck back on site every season.
Technical specificationsSKU: SSL-AL3/T3/150S/MW/22/120-347V/BK/D/SCR
Brand: TUROLIGHT
Selectable wattage: 150-100-70W
Lumens: 15 750-10 500-7 350lm
Colour temperature: 2200K
CRI: 80
Distribution: Type III
Voltage: 120-347V auto-sensing driver, 10KV surge protection device
Dimming: 0-10V
Rating: IP65, wet location
Operating temperature: -40˚C ~ +45˚C
Lifespan: L80 @ 100,000 hrs
Housing: Pressure die-cast aluminum, black
Lens: UV-resistant prismatic polycarbonate
Dimensions: 13.31" X 12.4" X 2.47" - L2 11.41"
Listings: cULus listed, DLC Premium
Warranty: 5 years
Wiring, controls and mountingThe auto-sensing
120-347V driver senses the incoming line, so the same fixture goes on a 120V feed or a 347V commercial service without changing the order — a real advantage on mixed sites and retrofits. A 10KV surge protection device guards against the spikes that kill outdoor drivers, and
0-10V dimming lets you tie the lot into a time clock, a control system or a scheduled reduction after closing. The fixture arrives complete with an installed photocell receptacle and a shorting cap: leave the cap in for constant or controlled operation, or swap it for the
SSL-AL3 120-347V photocell sensor to get automatic dusk-to-dawn switching. A spare
SSL-AL3 shorting cap is worth keeping in the truck. Mounting options include slipfitters, square or round pole mounts, adjustable trunnions and a small yoke — see the
pole bracket for LED floodlight in black and the
knuckle bracket for LED floodlight in black. Type IV and Type V lenses and a house shield are ordered separately.
Applications and documentationTypical projects: parking lots, roadways and drive aisles, auto dealership display rows, school and college campuses, contractor yards, self-storage sites, church and community centre lots, condo and apartment grounds. One pole at 150W covers a busy entrance; the same fixture set to 70W handles a quiet employee lot. Pair it around a building with matching TUROLIGHT wall lighting such as the
wallpack full cut-off MW (80W-100W-120W) for a consistent exterior package. The full technical spec sheet — ordering guide, dimensional drawing, mounting accessories and DLC information — is available in the Documentation tab of this page.
