SpecificationsVoltage: 24V DC
Wattage: 3W
Lumen output: 240 lm
Colour temperature: 3CCT, field-selectable 3000K / 4000K / 5000K
CRI: >90
Beam angle: 120°
Dimming: dimmable with compatible dimming power supplies
Installation: recessed mount, cutout Ø2-3/8” (60mm)
Trim diameter: Ø2-3/4” (70 mm)
Housing: aluminum + PMMA
Lead wire: 12” (30cm)
IP rating: IP20, indoor-rated
Lifespan: +50,000 hours
Warranty: 3 years
Trim finish: white
Included: LED light engine, integrated recessed trim, wire lead
Where the RD8 puck light shinesUse it for
cabinet lighting under upper kitchen cabinets, inside glass-door cabinets and pantries; for
display and showcase lighting in retail counters, jewellery cases and collection shelves; for
furniture and millwork such as bookcases, bars, closets and built-in wall units; and for
shelving and accent lighting that highlights art, bottles or decor. The slim, low-profile body keeps the fixture discreet once installed.
Installation tipsPlan the layout first, then drill a Ø2-3/8” (60mm) hole for each puck and press it into place. Connect the pucks in a
daisy chain to a single
24V DC power supply: add up the wattage of every puck on the run and choose a supply with spare capacity. For dimming, use a dimmable model such as the
24W 24V dimmable power supply, or a 5-in-1 dimmable driver like the
30W 24V 5-in-1 dimmable power supply or the
60W 24V 5-in-1 dimmable power supply for larger kitchens. Set the colour temperature on each puck before closing the cabinet so the whole run matches.
Good to knowThe RD8 is indoor-rated (IP20): keep it in dry areas such as cabinets, shelves and display furniture. It is also offered with black, white and brushed nickel trims, so you can match every cabinet finish in the same project. With a rated lifespan of +50,000 hours and a 3-year warranty, it is a long-term upgrade for kitchens, retail fixtures and furniture alike.
