RD8 RECESSED LED PUCK LIGHT - 24V - 3W - 240 LM - 3CCT 3000K/4000K/5000K - CRI 90+ - DIMMABLE - 12 IN WIRE LEAD - BLACK TRIM

RD8 RECESSED LED PUCK LIGHT - 24V - 3W - 240 LM - 3CCT 3000K/4000K/5000K - CRI 90+ - DIMMABLE - 12 IN WIRE LEAD - BLACK TRIM

SKU: LS-RD8-24V-3CCT-BK

Brand: LUMENSTARLED

The RD8 recessed LED puck light (LS-RD8-24V-3CCT-BK) is a low-profile 24V LED puck light made for kitchen cabinets, shelving, display cases and custom millwork. It draws only 3W yet delivers 240 lumens through a wide 120° beam, so a row of pucks gives even, uniform light instead of hot spots. The black trim disappears into dark cabinetry, espresso millwork and black hardware, so the eye sees the light, not the fixture.

Its field-selectable colour temperature lets you pick 3000K, 4000K or 5000K right on site: warm 3000K for a cozy kitchen or living room, neutral 4000K for retail shelving, crisp 5000K for showcases and work counters. A high CRI above 90 keeps wood, stone, food and merchandise looking natural.

The puck is dimmable with a compatible dimming power supply, switches on instantly and is designed for daisy-chain installation, which keeps long runs under upper cabinets fast and tidy. It installs recessed in a Ø2-3/8” (60mm) cutout with its integrated recessed trim and 12 in (30 cm) wire lead: a simple way to replace old halogen pucks with efficient, long-life LED under cabinet lighting. It suits homes as well as commercial spaces such as boutiques, restaurants, hotels and offices, wherever you want clean, discreet accent light.

Other versions of this product

29.97$


Spec sheet (PDF)

Description and specifications – LS-RD8-24V-3CCT-BK

Specifications
Voltage: 24V DC
Wattage: 3W
Lumen output: 240 lm
Colour temperature: 3CCT, field-selectable 3000K / 4000K / 5000K
CRI: >90
Beam angle: 120°
Dimming: dimmable with compatible dimming power supplies
Installation: recessed mount, cutout Ø2-3/8” (60mm)
Trim diameter: Ø2-3/4” (70 mm)
Housing: aluminum + PMMA
Lead wire: 12” (30cm)
IP rating: IP20, indoor-rated
Lifespan: +50,000 hours
Warranty: 3 years
Trim finish: black
Included: LED light engine, integrated recessed trim, wire lead

Where the RD8 puck light shines
Use it for cabinet lighting under upper kitchen cabinets, inside glass-door cabinets and pantries; for display and showcase lighting in retail counters, jewellery cases and collection shelves; for furniture and millwork such as bookcases, bars, closets and built-in wall units; and for shelving and accent lighting that highlights art, bottles or decor. The slim, low-profile body keeps the fixture discreet once installed.

Installation tips
Plan the layout first, then drill a Ø2-3/8” (60mm) hole for each puck and press it into place. Connect the pucks in a daisy chain to a single 24V DC power supply: add up the wattage of every puck on the run and choose a supply with spare capacity. For dimming, use a dimmable model such as the 24W 24V dimmable power supply, or a 5-in-1 dimmable driver like the 30W 24V 5-in-1 dimmable power supply or the 60W 24V 5-in-1 dimmable power supply for larger kitchens. Set the colour temperature on each puck before closing the cabinet so the whole run matches.

Good to know
The RD8 is indoor-rated (IP20): keep it in dry areas such as cabinets, shelves and display furniture. It is also offered with black, white and brushed nickel trims, so you can match every cabinet finish in the same project. With a rated lifespan of +50,000 hours and a 3-year warranty, it is a long-term upgrade for kitchens, retail fixtures and furniture alike.
