A square recessed light with a baffle trim
The CANOLIGHT square baffle light combines a 5-inch square face with a baffle-style trim. The ridged inner surface of a baffle absorbs stray light around the source, which cuts the harsh glare you often see from a bare lens and gives a softer, more even glow. The result is a square downlight that looks as good switched off as it does switched on, ideal when you want the ceiling to read as calm and orderly.
Light output and colour choice
With 12W of power and 1,000 lumens of output, this fixture is well suited to general lighting in residential and light commercial spaces. The 5CCT design lets you choose among five colour temperatures, including 2.7K, 3K, 3.5K and 4K. Warmer settings create a welcoming atmosphere in living rooms and bedrooms, while cooler settings help with tasks in kitchens, laundry rooms, garages and offices. Choosing the colour on site means you can match existing fixtures or adjust to the client's taste without reordering.
Electrical and installation details
The fixture is supplied with FT4 wire, a flame-tested cable rating commonly specified in Canada. Its power factor of 0.9 reflects efficient electrical performance. As with any recessed downlight, plan the layout before cutting: spacing the lights evenly across the ceiling, centring them over counters and keeping a consistent line along hallways gives the most professional result. Always have the installation done according to local electrical code, and refer to the spec sheet for the cut-out size and mounting method.
Where to use it
Think of a row of square pot lights over a kitchen island, a grid in a finished basement, accent lighting in a condo entrance, or clean general lighting in a dental office, a boutique or a meeting room. The square profile pairs especially well with modern cabinetry, square tiles and minimalist décor, where round lights can look out of place.
Technical specifications
Model: CL-BF1-S4012-5CCT-BL
Brand: CANOLIGHT
Size: 5 inches, square
Power: 12W
Luminous flux: 1,000 lm
Power factor: 0.9
Wiring: FT4 wire
Colour temperature: 5CCT, selectable (including 2.7K, 3K, 3.5K, 4K)
Documentation: spec sheet available in the Documentation tab
