2X2 FLAT PANEL TROFFER TRANSFORMER (32 PCS/PALLET) 120-277V

Name: 2X2 FLAT PANEL TROFFER TRANSFORMER (32 PCS/PALLET) 120-277V
Brand: LIGHT EFFICIENT DESIGN
SKU: RP-TTF-G1-2X2-20L-840-FWFC
Price: 160.99 CAD
Availability: InStock

SKU: RP-TTF-G1-2X2-20L-840-FWFC

Brand: LIGHT EFFICIENT DESIGN

Say goodbye to humming, flickering ceiling fixtures: the 2x2 Flat Panel Troffer Transformer from Light Efficient Design drops straight into your existing suspended ceiling grid and instantly modernizes the whole room. People search for it as a 2x2 LED panel, an LED ceiling panel, a flat panel troffer or simply a panel light — and this one is unusual because a single product works either as a door-style retrofit kit over an old fluorescent troffer or as a brand-new fixture. Its one-piece bracket design fits every single troffer, and the built-in trim covers the air gap around the frame, so you get a clean, seamless, no-gap look instead of the ugly shadow line other kits leave behind. Sold by the pallet (32 pieces), it's made for offices, schools, clinics and retail floors where every ceiling tile has to match.

This is the RP-TTF-G1-2X2-20L-840-FWFC, and it's built around FlexWatt and FlexColor slide switches you set with your finger in about 30 seconds. FlexWatt gives you 4 wattages in one fixture: 16W (2000-2032LM), 20W (2500-2540LM), 24W (3072-3120LM) or 28W (3584-3640LM). FlexColor gives you 3 selectable colour temperatures — 3500K, 4000K and 5000K — with 4000K as the shipped default for that crisp, neutral white. Add 80+ CRI, efficacy from 127 to 145 LPW, a power factor >0.9 with THD <15%, and universal 120-277V input (347V optional). The fixture comes with 1-10V dimming and a dim-to-off driver with 12V DC AUX power, operates from -4°F to 140°F, carries a PC lens, and is rated for >100,000 hours of life. It's UL 1598 listed as a fixture and UL 1598C listed as a retrofit kit.

Where does it shine? Open-plan offices, classrooms, medical and dental clinics, municipal buildings, corridors and back-of-house areas in Canadian commercial and institutional buildings — anywhere a 2x2 grid is already in place and a 3-minute install per fixture keeps labour costs down. Need other sizes for the same project? Pair it with the 1x4 flat panel troffer transformer and the 2x4 flat panel troffer transformer, or switch to the 2x2 volumetric troffer transformer when you prefer the softer volumetric look. Order your pallet and give the whole floor one consistent, modern ceiling.

One product, two installations
The Troffer Transformer TTF-G1 was engineered to end a long-standing headache: choosing between a door-style retrofit kit and a complete new fixture. This single 2x2 flat panel does both. Over an existing fluorescent troffer, it installs as a one-piece door retrofit kit; in a fresh grid, it goes in as a new fixture. The bracket is a single piece instead of multiple loose brackets, which is why it fits every single troffer and why a trained installer gets a fast 3-minute install rather than the 5 to 15 minutes (or more) typical of multi-piece kits. The integrated trim covers the air gap around the frame for a seamless finish on every ceiling tile.

Light quality and FlexWatt / FlexColor
Open the fixture and you'll find two slide switches. The FlexWatt switch has four positions for the 2x2 size: 16W (2000-2032LM), 20W (2500-2540LM), 24W (3072-3120LM) and 28W (3584-3640LM), so one SKU covers a classroom that needs a gentle wash and a drafting room that needs punch. The FlexColor switch has three positions — 3500K on top, 4000K in the middle, 5000K on the bottom — letting you match warm, neutral or cool white to the rest of the building. Default configuration ships at 4000K with 2032 lumens at 127 LPW. With 80+ CRI and a PC lens, colours read accurately and the diffused output stays comfortable for people working under it all day.

Electrical, dimming and controls
Universal 120-277V input covers virtually every North American commercial service, and 347V is available as an option. The driver delivers a power factor greater than 0.9 with THD under 15%, and it is a dim-to-off driver with 12V DC AUX power plus standard 1-10V dimming. That AUX output is what makes sensor integration clean: the fixture can be used with a basic PIR fixture-level control or with an advanced Bluetooth mesh sensor control system. Ordering options on this platform include -OCC (high/low motion sensor), -EMG (90-minute emergency battery backup) and -AIR (air return trim); advanced control options are also available. Operating temperature range is -4°F to 140°F.

Technical specifications
SKU: RP-TTF-G1-2X2-20L-840-FWFC
UPC: 844006053260
Style: Flat panel (TTF), size 2x2
Wattage (FlexWatt): 16/20/24/28
Default lumens: 2032
Efficacy: 127 LPW (range 127-145 LPW)
CCT (FlexColor): 3500/4000/5000K, default 4000K
CRI: 80+
Voltage: 120-277V (347V optional)
Power factor / THD: >0.9 / <15%
Dimming: 1-10V, dim-to-off driver, 12V DC AUX
Lens: PC
Operating temperature: -4°F to 140°F
Rated life: >100,000 hours
Listings: UL 1598 listed fixture, UL 1598C listed retrofit kit
Pallet quantity: 32 pieces (case quantity of 4)

Applications, compatibility and documentation
Think office floor retrofits done one suite at a time, school and college classroom upgrades over a summer, clinic exam rooms, government offices, corridors, libraries and retail stockrooms — any Canadian building with a standard 2x2 suspended grid. Buying a full pallet keeps wattage, colour temperature and finish matched across the job, and the field-adjustable switches let you fine-tune zone by zone after the ceiling is closed. Mixed grids are easy to cover: use the 1x4 flat panel troffer transformer in corridors, the 2x4 flat panel troffer transformer in open areas, and the volumetric versions — 2x2 volumetric troffer transformer or 1x4 volumetric troffer transformer — where a recessed, dimensional look is preferred. The full technical PDF spec sheet for this model is in the Documentation tab, including the ordering guide, the FlexWatt and FlexColor switch tables and the DLC codes your utility rebate program will ask for.
